2505 2635 34 01

Bush (Reverse Idler Gear)

2505 2635 34 01

—

8854 2604 16 12

Synchro Kit GBS 40 Consisting of :

8854 2604 16 12

—

1

Drive Shaft (6.34)

2505 2625 79 04

—

2

Compression Spring

321 993 12 01

—

3

Clamping Plate

321 262 00 73

—

4

Cylindrical Roller Bearing

000 981 12 01

—

5

Snap Ring 2.73 mm Thick

2505 2620 43 03

—

5

Snap Ring 2.68 mm Thick

2505 2620 43 02

—

5

Snap Ring 2.93 mm Thick

2505 2620 43 07

—

5

Snap Ring 2.83 mm Thick

2505 2620 43 05

—

5

Snap Ring 2.78 mm Thick

2505 2620 43 04

—

5

Snap Ring 2.88 mm Thick

2505 2620 43 06

—

6

Four Point Ball Bearing

2505 2620 31 06

—

7

Spacer on Drive Shaft

2507 2625 86 01

—

8

Lock Nut LH Thread

312 262 11 72

—

9

Roller Cage (31mm Long)

2505 2620 31 18

—

10

Main Shaft (w/o groove)

2505 2620 79 03

—

11

Pressure Spring

312 993 17 01

—

12

Pin on Main Shaft

321 262 03 74

—

13

Butting Ring 7.55 mm Thick

For Selection

321 262 29 62

—

13

Butting Ring 7.60 mm Thick

For Selection

321 262 06 62

—

13

Butting Ring 7.65 mm Thick

For Selection

321 262 30 62

—

13

Butting Ring 7.70 mm Thick

For Selection

321 262 07 62

—

13

Butting Ring 7.75 mm Thick

For Selection

2505 2620 86 13

—

13

Butting Ring 7.25 mm Thick

For Selection

2505 2620 86 11

—

13

Butting Ring 7.80 mm Thick

For Selection

321 262 25 62

—

13

Butting Ring 7.85 mm Thick

For Selection

2505 2620 86 14

—

13

Butting Ring 7.90 mm Thick

For Selection

321 262 26 62

—

13

Butting Ring 7.95 mm Thick

For Selection

2505 2620 86 15

—

13

Butting Ring 8.00 mm Thick

For Selection

321 262 27 62

—

13

Butting Ring 7.50 mm Thick

For Selection

321 262 05 62

—

13

Butting Ring 7.45 mm Thick

For Selection

321 262 28 62

—

13

Butting Ring 7.40 mm Thick

For Selection

321 262 04 62

—

13

Butting Ring 7.35 mm Thick

For Selection

2505 2620 86 12

—

13

Butting Ring 7.30 mm Thick

For Selection

321 262 17 62

—

13

Butting Ring 7.20 mm Thick

For Selection

321 262 18 62

—

13

Butting Ring 7.15 mm Thick

For Selection

2505 2620 86 10

—

13

Butting Ring 7.10 mm Thick

For Selection

321 262 19 62

—

13

Butting Ring 7.05 mm Thick

For Selection

2505 2620 86 09

—

13

Butting Ring 7.00 mm Thick

For Selection

321 262 20 62

—

13

Butting Ring 6.95 mm Thick

For Selection

2505 2620 86 08

—

13

Butting Ring 6.90 mm Thick

For Selection

321 262 21 62

—

14

Synchronising Ring

322 262 01 34

—

16

Synchronising Sleeve 4th & 5th

2505 3015 54 03

—

17

Comp. Spring

—

18

Retention Pin 1st

—

18

Retention Pin 4/5, 2/3

—

19

Carrier 4/5 & 2/3

—

20

Synchronising Cone

2505 2620 38 02

—

20

Synchronising Cone

2505 2620 38 02

—

20

Synchronising Cone

2505 2620 38 02

—

21

Shifting Sleeve

321 262 08 23

—

22

Assy. Helical Gear 4th Speed

2505 2620 01 35

—

23

Double Row Needle Cage

2505 2620 31 23

—

24

Collar Bushing 44.5 mm Long (For Third Speed Gear)

For Selection

322 262 40 50

—

24

Collar Bushing 44.6 mm Long (For Third Speed Gear)

For Selection

322 262 41 50

—

25

Double Row Roller Cage

2505 2620 31 24

—

25

Double Row Roller Cage

2505 2620 31 24

—

26

Assy. Helical Gear 3rd Speed

2505 2620 01 18

—

28

Synchronising Sleeve 2/3

322 262 04 35

—

29

Shifting Sleeve

321 262 08 23

—

30

Helical Gear 2nd Speed

322 262 01 12

—

32

Reverse Gear on Main Shaft

322 263 03 33

—

33

Carrier 1st

—

34

Shifter Sleeve 1st Speed

321 262 07 23

—

35

Collar Bushing 47.7 mm Long

2505 3015 34 06

—

35

Collar Bushing 47.2 mm Long

2505 3015 34 01

—

35

Collar Bushing 47.3 mm Long

2505 3015 34 02

—

35

Collar Bushing 47.4 mm Long

2505 3015 34 03

—

35

Collar Bushing 47.5 mm Long

2505 3015 34 04

—

35

Collar Bushing 47.6 mm Long

2505 3015 34 05

—

35

Collar Bushing 47.8 mm Long

2505 3015 34 07

—

35

Collar Bushing 47.9 mm Long

2505 3015 34 08

—

36

Cylindrical Roller 4x8

2505 2620 30 01

—

37

Gear Wheel 1st Speed

2505 3015 54 01

—

38

Gear Speedometer Drive

352 264 01 30

—

39

Shaft (Speedo Drive)

2505 2620 79 02

—

40

Gear Speedometer Drive

352 264 01 30

—

41

Coupling Flange (8 Holes)

322 262 00 45

—

42

Hex. Nut

322 262 00 72

—

43

Counter Shaft (W/o PTO Provision)

For LP 613

2505 2630 79 01

—

43

Counter Shaft (With PTO Provision)

For LPT 613

2505 3014 79 01

—

44

Twin Gear (Counter Shaft) (2/3)

2505 2630 54 02

—

45

4th Gear (On Counter Shaft)

2505 2630 54 01

—

46

Constant Mesh Gear (On Counter Shaft) (6.34)

2505 2630 54 07

—

47

Circlip A 52x2.5

1455 069905 3

—

48

Taper Roller Bearing

2505 2630 31 04

—

49

Reverse Idler Gear with Bush

2505 2635 01 02

—

51

Reverse Idler Gear Shaft

2505 3017 79 01

—

Каталог запасных частей к технике: Tata LP/LPT 613 LHD. GEAR SHAFT AND GEAR
