2505 2625 82 01

Oil Slinger (Front Cover)

2505 2625 82 01

—

2505 2620 78 03

Oil Seal

2505 2620 78 03

—

321 261 03 33

Cover (For PTO Application)

For LPT 613

321 261 03 33

—

2505 2640 53 03

Gasket (For Cover)

For LPT 613

2505 2640 53 03

—

2505 2671 34 07

Stopper Piece Check Plate

2505 2671 34 07

—

2505 2671 34 03

Support Piece Check Plate

2505 2671 34 03

—

2505 2600 01 01

Gear Box Gasket Kit Consisting of :

2505 2600 01 01

—

8854 2605 16 13

Overhauling Kit - GB 40 consisting of :

8854 2605 16 13

—

Oil Seal

—

Oil Seal (Front Cover)

—

Shim 0.10 mm Thick

—

Shim 0.20 mm Thick

—

Shim 0.40 mm Thick

—

Shim 0.05 mm Thick

—

Shim 0.80 mm Thick

—

Gasket (GB cover Lower to GB Housing)

—

Gasket (Front cover Top to GB Housing)

—

Gasket (GB cover RR)

—

Gasket (GB Top cover)

—

Hex Collar Nut

—

Hex Nut

—

Pressure Spring

—

Pin Main Shaft

—

1

Assy. GBS - 40 - 5 / 6.34 8 BCF PTO provision, Full Remote LHD

For LPT 613

2505 2604 01 80

—

1

Assy. GBS - 40 - 5 / 6.34 6 BCF, Full Remote LHD

For LP 613

2505 2604 01 24

—

2

Gear Box Housing (6.34 Ratio)

2505 2610 37 22

—

3

Cylindrical Pin 10 H 8x20

1305 090920 9

—

4

Plug Oil Filling

000 997 00 06J

—

5

Magnetic Drain Plug (Hex head type)

2506 2610 72 03

—

6

Gasket

2505 3014 53 01

—

6

Gasket Front Cover Lower

—

7

Front Cover Lower

2505 3014 47 01

—

11

Gasket (Fr. Cover Top to Hsg.)

2505 2625 53 01

—

11

Gasket Front CoverUpper

—

12

Gear Box Housing Cover Front Top

2505 3013 47 01

—

15

Oil Seal

2505 2625 78 08

—

16

Butting Ring 2.90 mm Thick

For Selection

2505 3013 86 01

—

16

Butting Ring 2.95 mm Thick

For Selection

2505 2625 86 01

—

16

Butting Ring 3.00 mm Thick

For Selection

2505 3013 86 02

—

16

Butting Ring 3.05 mm Thick

For Selection

2505 2625 86 02

—

16

Butting Ring 3.10 mm Thick

For Selection

2505 3013 86 03

—

16

Butting Ring 3.15 mm Thick

For Selection

2505 2625 86 03

—

16

Butting Ring 3.20 mm Thick

For Selection

2505 3013 86 04

—

16

Butting Ring 3.25 mm Thick

For Selection

2505 2625 86 04

—

16

Butting Ring 3.30 mm Thick

For Selection

2505 3013 86 05

—

16

Butting Ring 3.35 mm Thick

For Selection

2505 2625 86 05

—

16

Butting Ring 3.40 mm Thick

For Selection

2505 3013 86 06

—

16

Butting Ring 3.45 mm Thick

For Selection

2505 2625 86 06

—

16

Butting Ring 3.50 mm Thick

For Selection

2505 3013 86 07

—

16

Butting Ring 3.60 mm Thick

For Selection

2505 3013 86 08

—

17

Gear Case Cover Rear

2505 3015 37 01

—

19

Adaptor

321 261 00 31

—

20

Assy. Threaded Bush

321 260 00 86

—

21

Plug Speedo Drive

153 264 00 55

—

23

Shim 0.05 mm Thick

For Selection

312 283 17 52

—

23

Shim 0.1 mm Thick

For Selection

312 283 10 52

—

23

Shim 0.2 mm Thick

For Selection

312 283 11 52

—

23

Shim 0.4 mm Thick

For Selection

312 283 12 52

—

23

Shim 0.8 mm Thick

For Selection

312 283 21 52

—

27

Gasket (Gear Case Cover Rear)

352 261 07 80

—

27

Gasket Rear Cover

—

30

Gear Case Cover Top (Lower Half)

2505 2671 37 55

—

31

Gasket

2505 3014 53 01

—

31

Gasket Top Cover

—

32

Stud

2505 3012 88 01

—

33

Pin Swing Lever

2505 2671 67 01

—

37

Pressure relief Valve

2668 3515 01 02

—

38

Thrust Pin (Reverse Indicator Switch)

2505 3011 67 01

—

39

Pressure Spring (Reverse Indicator Switch)

312 993 42 01

—

40

Reverse Indicator Switch

2654 5450 01 34

—

41

Swing Lever - 1st Speed

2505 2670 51 05

—

42

Washer (Swing Lever)

2505 3012 92 01

—

43

Pressure Piece for Check Plate

2505 2671 34 09

—

44

Pressure Spring for Pressure Piece

2505 2671 87 02

—

45

Slotted Plug

321 997 01 03

—

46

Interlocking Pin

2505 2671 34 10

—

47

Pressure Spring for Interlocking Pin

321 993 06 01

—

48

Sealing Plug M 24x1.5

1608 250240 1

—

49

Assy. Check Plate

321 260 08 46

—

54

Selector Shaft for First Speed

321 265 08 05

—

55

Selector Shaft (2/3)

321 265 18 05

—

56

Selector Shaft (4/5)

321 265 19 05

—

57

Selector Shaft (For Reverse Gear)

322 265 03 05

—

58

Gear Shift Dog (For First Gear)

322 265 01 23

—

59

Selector Fork (2/3)

321 265 12 02

—

60

Selector Fork (4/5)

2505 2651 51 02

—

61

Selector Fork (For 1st Speed Gear)

321 265 13 01

—

62

Selector Fork (For Reverse Gear)

2505 2651 51 01

—

63

Pressure Spring

312 993 10 01

—

64

Steel Ball 11 mm dia.

1595 010110 2

—

65

Clamp (Selector Shaft to Gear Box Housing)

312 265 10 36

—

66

Locking Plate (Selector Shaft to Gear Box Housing)

312 994 03 32

—

67

Cover Top (Upper Half)

2505 2671 37 56

—

68

Needle Bearing

2507 2671 31 05

—

69

Shifter Finger

2505 2670 51 04

—

70

Selector & Shifter Shaft

2505 2670 79 09

—

73

Oil Seal

1706 160251 8

—

74

Scraper Ring

2507 2671 78 03

—

75

Shifting Lever

2507 2670 60 13

—

76

Cap

2505 2671 82 22

—

77

Bellow

2505 2671 77 01

—

78

Hose Clip 25

1427 020250 1

—

79

Gasket (Between Upper & Lower Half)

2506 2671 53 01

—

83

Sliding Key

321 265 08 49

—

Каталог запасных частей к технике: Tata LP/LPT 613 LHD. GEAR BOX HOUSING
