1

MUFFLER

Standard

87369371

—

1

MUFFLER

Spark Arrester, South Africa Only

87369363

—

2

GASKET

226775A1

—

3

STUD

387795A1

—

4

WASHER

387798A1

—

5

NUT

387796A1

—

6

SUPPORT

87588155

—

7

NUT

M12x1.75, Flg, Cl 10,

829-2412

—

8

HOSE

HOSE, Flexible, Order REF 32 87520146 For Initial Replacement, BSN Z6RZ02856

HOSE

—

9

TUBE ASSY

87607503

—

10

CLAMP

Inc. Hardware

A170807

—

11

BRACKET

Manifold Shield

87451651

—

12

BOLT

Hex Flg, M10x16, 8.8, Full Thd,

844-10016

—

13

SHIELD

Turbo Heat, Shown, Magnum 225, 250, 280, and 310

87615756

—

13

SHIELD

Turbo Heat, Magnum 335

87715386

—

15

BRACKET

Heat Shield, Turbo

87615566

—

16

WASHER

.344dmx1 1/4dmx.120dm, Magnum 225, 250, 280, and 310

495-81120

—

16

WASHER

.344dmx1 1/4dmx.120dm, Magnum 335

495-81120

—

18

EXTENSION

Exhaust

87381922

—

19

CLAMP

87449404

—

21

INSULATION

FOAM, Exhaust, Shown, Magnum 225, 250, 280, and 310

87325972

—

21

INSULATION

FOAM, Exhaust, Magnum 335

87620835

—

22

CLAMP

HOSE, 4.25/5.125 HD Worm, W/liner,

214-3280

—

23

SPACER

87332194

—

24

STUD

87330610

—

25

TUBE

TUBE ASSY., Order REF 32 87520146 For Initial Replacement, BSN Z6RZ02856

TUBE

—

26

CLAMP

87449404

—

27

CLAMP

BSN Z6RZ02856

87427885

—

27

CLAMP

ASN Z6RZ02856

87427885

—

28

BRACKET

Turbo Heat Shield, Magnum 225, 250, 280, and 310

87449823

—

28A

BRACKET

Turbo heat Shield, Magnum 335

87715390

—

29

NUT

M8x1.25, Flg, Cl 8,

825-2408

—

30

BOLT

Hex Flg, M10x20, 8.8,

844-10020

—

31

BOLT

Hex Flg, M8x20, 8.8, Magnum 225, 250, 280, and 310

844-8020

—

31

BOLT

Hex Flg, M8x20, 8.8, Magnum 335

844-8020

—

32

TUBE ASSY

Shown, Magnum 225, 250, 280, and 310, ASN Z6RZ02856

87520146

—

32

TUBE ASSY

Magnum 335

87714128

—

Каталог запасных частей к технике: Cummins 310. EXHAUST SYSTEM
