10

Duct plate

4182.306.005

—

20

Drain valve

KPL.

4149.206.086

—

22

Spring sheet

WANDLERENTLEERVENTIL

4149.306.138

—

24

Torx screw

M6X16 IN 0736 101 3632,C0100799 3210

0736.101.358

—

30

Intermplate

DRWK

4182.306.007

—

58

Valve block

KPL.A C WK F 24V 2P

4182.206.005

—

58.10

Valve block

4182.306.001

—

58.20

Piston

4149.306.153

—

58.22

Piston

4182.306.002

—

58.40

Comprspring

0732.041.148

—

58.42

Comprspring

0732.041.095

—

58.44

Comprspring

0732.041.148

—

58.46

Comprspring

0732.042.960

—

58.50

Washer

A=4,00 IN 0730 009 2962

0730.009.221

—

58.52

Bush

4182.306.004

—

58.60

Piston

KPL.

4139.206.415

—

58.62

Piston

KPL. ECOMAT 4

4182.206.001

—

58.70

Gasket

4139.306.541

—

58.80

Cover plate

4139.306.001

—

58.90

Torx screw

M6X16 IN 0736 101 3632,C0100799 3210

0736.101.358

—

58.110

Valve strip

WBH/ECOMAT 2PLUS, C0100909 4E10

4149.306.241

—

58.120

O-ring

5X1,5

0634.313.074

—

58.130

Ball

4

0635.460.004

—

58.140

Bush

ENTHALT.IN 4139 306 2182

4139.306.219

—

58.150

O-ring

24X3

0634.316.217

—

58.160

4139.306.217

—

58.170

Washer

0730.002.769

—

58.172

Retaining ring

20X1

0630.502.007

—

58.180

Piston

4139.306.085

—

58.200

Orifice

D=0,8 IN 0730 361 1202

0730.361.070

—

58.202

Orifice

D=0,7 IN 0730 361 1202

0730.361.078

—

58.204

Orifice

D=0,9 IN 0730 361 1202

0730.361.095

—

58.206

Orifice

A=1,00 IN 0730 361 1202

0730.361.077

—

58.210

Comprspring

0732.041.374

—

58.220

Gasket

4139.306.545

—

58.230

Cover plate

4139.306.125

—

58.240

Piston

4149.306.068

—

58.250

Comprspring

0732.041.373

—

58.280

Torx screw

M6X65 IN 0736 101 3632,C0100799 3210

0736.101.360

—

58.290

Torx screw

M6X16 IN 0736 101 3632,C0100799 3210

0736.101.358

—

58.310

Solenoid valve

24V 2POL

0501.319.200

—

58.320

Cap screw

M5X12

0636.101.651

—

58.320

Washer

0630.001.096

—

60

Cover plate

ENTHALT.IN 4139 306 1771

4139.306.179

—

70

Torx screw

M6X65 IN 0736 101 3632,C0100799 3210

0736.101.360

—

100

Ball

5

0635.460.077

—

110

Gasket

4139.306.667

—

128

Valve block

KPL.B E D 24V 2P ECO 2PLUS

4149.206.164

—

128.110

Valve block

ECOMAT 2PLUS

4149.306.238

—

128.120

Piston

4149.306.153

—

128.150

Stop

ENTHALT.IN 4149 306 1262

4149.306.127

—

128.160

Comprspring

0732.042.683

—

128.170

Comprspring

0732.042.683

—

128.180

Comprspring

0732.042.683

—

128.200

Washer

A=4,00 IN 0730 009 2962

0730.009.221

—

128.220

Piston

KPL.

4139.206.415

—

128.230

Piston

G2.1 O.NBS

4149.306.116

—

128.234

Gasket

4139.306.541

—

128.240

Cover plate

4139.306.001

—

128.250

Torx screw

M6X16 IN 0736 101 3632,C0100799 3210

0736.101.358

—

128.260

Valve strip

WBH/ECOMAT 2PLUS, C0100909 4E10

4149.306.241

—

128.270

O-ring

5X1,5

0634.313.074

—

128.280

Ball

4

0635.460.004

—

128.290

Bush

ENTHALT.IN 4139 306 2182

4139.306.219

—

128.310

O-ring

24X3

0634.316.217

—

128.330

4139.306.217

—

128.350

Washer

0730.002.769

—

128.370

Retaining ring

20X1

0630.502.007

—

128.390

Piston

4139.306.085

—

128.400

Piston

4139.306.429

—

128.402

Orifice

D=0,8 IN 0730 361 1202

0730.361.070

—

128.404

Orifice

D=0,8 IN 0730 361 1202

0730.361.070

—

128.406

Orifice

D=0,8 IN 0730 361 1202

0730.361.070

—

128.410

Comprspring

0732.041.374

—

128.430

Piston

4149.306.068

—

128.450

Comprspring

0732.041.373

—

128.464

Gasket

4139.306.545

—

128.470

Cover plate

4139.306.125

—

128.490

Torx screw

M6X65 IN 0736 101 3632,C0100799 3210

0736.101.360

—

128.510

Torx screw

M6X16 IN 0736 101 3632,C0100799 3210

0736.101.358

—

128.520

Solenoid valve

24V 2POL

0501.319.200

—

128.530

Cap screw

M5X12

0636.101.651

—

128.530

Washer

0630.001.096

—

128.534

Shackle

Z0000151 7610

4182.306.014

—

128.550

4139.306.039

—

128.560

O-ring

13X1,5

0634.314.427

—

128.580

Cap screw

M5X12

0636.101.651

—

128.580

Washer

0630.001.096

—

130

Cover plate

4149.306.013

—

150

Torx screw

M6X65 IN 0736 101 3632,C0100799 3210

0736.101.360

—

160

Torx screw

M6X80 IN 0736 101 3632,C0100799 3210

0736.101.361

—

180

Gasket

G2-1

4149.306.114

—

240

Throttle valve

KPL.

4149.206.088

—

240.110

Valve block

G2.1-D1/D8

4149.306.129

—

240.120

Piston

ENTHALT.IN 4149 306 1321

4149.306.133

—

240.130

Piston

4139.306.677

—

240.140

Comprspring

LINKSGEWICKELT, C0100391 5D10

0732.042.923

—

240.160

Fixing plate

G2.1

4149.306.131

—

240.180

Solenoid

Dl-VENTI1,C0100528 9B10

0501.316.656

—

240.190

Torx screw

M5X12

0736.101.362

—

240.200

Solenoid valve

24V 2PO1,C0100190 9C10

0501.319.200

—

240.210

Cap screw

M5X12

0636.101.651

—

240.210

Washer

0630.001.096

—

290

Torx screw

M6X58

0736.101.557

—

294

Torx screw

M6X80 IN 0736 101 3632,C0100799 3210

0736.101.361

—

310

Wiring harness

KPL.ECOMAT 2 5/6SG 2-NTC

4149.206.098

—

310.200

Temperature sensor

KPL.L1=155MM 2-NTC/SLK-ST.

4149.206.107

—

340

Converter valve

KPL.

4139.206.545

—

344

Snap ring

0630.513.205

—

590

Solenoid

4139.306.673

—

600

Screw plug

M42X2,C0100117 4C10

0636.301.069

—

610

Torx screw

M8X43 IN 0736 617 0562

0736.617.075

—

612

Torx screw

M8X48 IN 0736 617 0562

0736.617.069

—

620

Torx screw

M8X35 IN 0736 617 0562

0736.617.066

—

630

Torx screw

M8X43 IN 0736 617 0562

0736.617.075

—

640

Indtransmitter

0501.314.432

—

640

Washer

A=6, 00 IN 0730 008 4162

0730.008.442

—

640

Washer

A=5,80 IN 0730 008 4162

0730.008.441

—

640

Washer

A=5,60 IN 0730 008 4162

0730.008.440

—

640

Washer

A=5,40 IN 0730 008 4162

0730.008.439

—

640

Washer

A=5,20 IN 0730 008 4162

0730.008.438

—

640

Washer

A=5,00 IN 0730 008 4162

0730.008.437

—

640

Washer

A=4,80 IN 0730 008 4162

0730.008.436

—

640

Washer

A=4,60 IN 0730 008 4162

0730.008.435

—

640

Washer

A=4,40 IN 0730 008 4162

0730.008.434

—

640

Washer

A=4,20 IN 0730 008 4162

0730.008.433

—

640

Washer

A=4,00 IN 0730 008 4162

0730.008.432

—

640

Washer

A=3,80 IN 0730 008 4162

0730.008.431

—

640

Washer

A=3,60 IN 0730 008 4162

0730.008.430

—

640

Washer

A=3,20 IN 0730 008 4162

0730.008.429

—

640

Washer

A=3,00 IN 0730 008 4162

0730.008.428

—

640

Washer

A=2,90 IN 0730 008 4162

0730.009.198

—

640

Washer

A=2,80 IN 0730 008 4162

0730.008.427

—

640

Washer

A=2,70 IN 0730 008 4162

0730.009.197

—

640

Washer

A=2,60 IN 0730 008 4162

0730.008.426

—

640

Washer

A=2,50 IN 0730 008 4162

0730.009.196

—

640

Washer

A=2,40 IN 0730 008 4162

0730.008.425

—

640

Washer

A=2,20 IN 0730 008 4162

0730.008.424

—

640

Washer

A=2,10 IN 0730 008 4162

0730.009.195

—

640

Washer

A=2,00 IN 0730 008 4162

0730.008.423

—

640

Washer

A=1,90 IN 0730 008 4162

0730.009.194

—

640

Washer

A=1,80 IN 0730 008 4162

0730.008.422

—

640

Washer

A=1,70 IN 0730 008 4162

0730.009.193

—

640

Washer

A=1,60 IN 0730 008 4162

0730.008.421

—

640

Washer

A=1,50 IN 0730 008 4162

0730.009.192

—

640

Washer

A=1,40 IN 0730 008 4162

0730.008.420

—

640

Washer

A=1,30 IN 0730 008 4162

0730.009.191

—

640

Washer

A=1,20 IN 0730 008 4162

0730.008.419

—

640

Washer

A=1,00 IN 0730 008 4162

0730.008.418

—

640

Washer

A=0,80 IN 0730 008 4162

0730.008.417

—

650

Torx screw

M6X45 IN 0736 101 3632,C0100799 3210

0736.101.359

—

660

O-ring

4X1,5

0634.313.016

—

670

Hexagon bolt

M8X28, Z0000705 9116

0636.016.414

—

670

Washer

Z0000705 9116

0630.001.075

—

800

Valve block

KPL.F2

4149.206.034

—

800.110

Valve housing

F2 UMSCHALTVENTIL/EC02

4149.306.051

—

800.120

Piston

4139.306.677

—

800.130

Comprspring

LINKSGEWICKELT, C0100337 8D10

0732.042.923

—

800.140

Screw plug

Ml 6X1,5

0636.302.065

—

800.140

Sealing ring

16X20

0634.801.045

—

810

Torx screw

M6X80 IN 0736 101 3632,C0100799 3210

0736.101.361

—

820

Valve block

UMSCHALTVENTIL DRWK

4182.206.008

—

820.110

Valve housing

UMSCHLTV. DRWK

4182.306.006

—

820.120

Piston

4149.306.068

—

820.130

Comprspring

0732.041.373

—

820.140

Fixing plate

UMSCHLTV. DRWK

4182.306.008

—

830

Torx screw

M6X30 IN 0736 101 3632

0736.101.374

—

Каталог запасных частей к технике: King Long XMQ-6127J. SHIFT CONTROL
