Каталог запасных частей к технике: Golden Dragon XML6105CN-7150227. CONTROL AND FRONT BRAKE

← ARRANGEMENT DIAGRAM, BRAKE AIR CYLINDER AND 4-WAY PROTECTIVE VALVE →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Hand brake valve

9617230380

Кран тормозной (ручник, 2 вывода) (КМ9617230150)

Уточняйте

Mounting plate, hand brake

XML3500091C5F0

—

Muffler

4324070600

—

Master valve

4613180710

—

Muffler

4324070700

—

Quick release valve

9735000000

—

Screw plug, outer Hex

JB1000-M16X1.5

—

Pall tube

8.2, yellow12x1.5

PAG12X1.5-Y

—

Pall tube

9.5, red12x1.5

PAG12X1.5-R

—

Pall tube

8.5, brown12x1.5

PAG12X1.5-H

—

Pall tube

grass green12x1.5

PAG12X1.5-C

—

Pall tube

blue12x1.5

PAG12X1.5-L

—

Pall tube

white12x1.5

PAG12X1.5-B

—

Straight connector, bite-type end

GB3733.1-G12

—

Straight thread elbow connector

GB3752.1-G12

—

Connector, PVC valve

6100A-3500351

—

Thread rubber tube

KTJG12-650

—

−

40%
