Каталог запасных частей к технике: Golden Dragon XML6105CN-7150227. AIR CYLINDER AND 4-WAY PROTECTIVE VALVE

← CONTROL AND FRONT BRAKE AIR SUPPLY →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Air cylinder assy

35L

6105Y12-3513020-HXLG

—

Air cylinder assy

40L

6105Y12-3513010-HXLG

—

Clamp, air cylinder

6100A2-3500101

—

Bracket, air cylinder

6105E05-3500102-BZ39

—

Bracket, air cylinder

6105E05-3500102-DQ35

—

Connector, water drain, air cyinder

Not retail

3500-911-J4C

—

Water drain valve, air cyinder

35360010060

—

4-way protective valve

9347141100

—

Air pressure sensor

360-018-063-001C

—

Transition connector, air pressure sensor

6127A01-3513013

—

Connector, door pump

Not retail

XML3500251N5F0

—

Pall tube

8x1

PAG8X1

—

Connector

WT001

—

Straight adjustable thread elbow connector

Not retail

XML3506004K3G0

—

Combined thread three-way pipe

Not retail

GB3753.1-G12

—

Straight thread elbow connector

Not retail

Q/108.1-12/3/8

—

−

40%
