Каталог запасных частей к технике: XCMG XGA3250d2WC. 453523434 AUXILIARY BRAKE-1

← 453524415 PARKING BRAKING 453523433 AUXILIARY BRAKE-2 →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

HEXAGON FLANGE FACE BOLT

Q1850825

805050226

—

HEXAGON FLANGE BOLTS-FINE PITCH

Q1850860

805050235

—

MULTI-WAY CONNECTOR BODY BRACKET

453504100

—

SNAP RING

CIRCLIP NG8

453505139

—

ABNORMAL SHAPE SEALING RING

RUBBER GASKET NG8

453505140

—

BOLT

NUT SEAT NG8

453505138

—

AUXILIARY GAS MODULE

PLUG NG12/6-NG8 WITH AUXILIARY GAS MODULE BELT

453505141

—

HYDRAULICALLY OPERATED O-TYPE RUBBER SEAL RING

Q734B1400265

805805925

—

END PIPE COUPLING

END THROUGH CONNECTOR BODY M16xl.5/G10

453502006

—

HEXAGON CHIP REMOVAL NUT WITH FLANGE

Q32108

805239499

—

FERRULE TAPERED THREAD RIGHT-ANGLE CONNECTOR

Q80806

805805955

—

ELBOW

BENT CONNECTOR BODYM12xl.5/G6

453505135

—

HYDRAULICALLY OPERATED O-TYPE RUBBER SEAL RING

Q734B1000180

805805923

—

COMPRESSION NUT

COMPRESSION NUT M1 x1.S

453503637

—

END PIPE COUPLING

END THROUGH CONNECTOR BODY M12xl.5/G6

453500793

—

ELBOW

BENT CONNECTOR BODYM12xl.5/G10

453500169

—

SEALING WASHER

Q72312T3

805339152

—

ELBOW

BENT CONNECTOR BODYM12xl.5/G5

453501585

—

−
