Каталог запасных частей к технике: XCMG XGA3250d2WC. 452900382 FRONT LEAF SPRING BRACKET ASSEMBLY

← 452901997 LEFT FRONT LEAF SPRING ASSEMBLY 452900073 SHOCK ABSORBER ASSEMBLY →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

FIXED END BRACKET (RIGHT) - FRONT SUSPENSION

452903445

—

HEXAGON HEAD BOLT-FINE THREAD

Q151B12115

805049723

—

STEEL PLATE SPRING PIN - FOR FIXING END BRACKET

452902664

—

BENDING GREASE NOZZLE

Q701B45

805805922

—

TYPE 1 HEXAGON NUT - FINE TEETH

Q341B12

805239591

—

STEEL PLATE SPRING PIN FOR LIFTING LUG

452903412

—

POSITIONING BOLT OF SPRING PIN

452902661

—

LIFTING LUG WITH SLEEVE ASSEMBLY - REAR SUSPENSION

452903416

—

STRAIGHT-THROUGH TYPE GREASE NOZZLE

Q700B01

805805921

—

LIFTING LUG PIN - FOR LIFTING LUG BRACKET

452902668

—

SIDE WASHER

452903417

—

SIDE WASHER

452903413

—

LIFTING LUG BRACKET (RIGHT) - FRONT SUSPENSION

452903447

—

LIFTING LUG BRACKET (LEFT) - FRONT SUSPENSION

452903446

—

HEXAGON FLANGE LOCK NUT

805239445

—

HEXAGON FLANGE FACE BOLT

Q1851440TF2

805050327

—

FIXED END BRACKET (LEFT) - FRONT SUSPENSION

452903444

—

HEXAGON FLANGE FACE BOLT

Q1851430TF2

805050319

—

WASHER 12

860123356

—

−

40%

452900382 FRONT LEAF SPRING BRACKET ASSEMBLY
