1

ENGINE MOUNTING SYSTEM

451013934

—

2

SUPPLY SYSTEM

(400L IRON TANK)

451106300

—

3

EXHAUST SYSTEM

451206644

—

4

COOLING SYSTEM

451308806

—

5

CLUTCH SYSTEM (31500N)

GUILINFUDA 10JSD140

451600837

—

6

TRANSMISSION SYSTEM

G22518

451705450

—

7

DRIVE SHAFT SYSTEM

HANDBRIDGE 9JSD150A

452205404

—

8

REAR AXLE SYSTEM

452400058

—

9

MIDDLE BRIDGE SYSTEM

452500190

—

10

FRONT BUMPER SYSTEM-EASY MAINTENANCE WITH FRONT UNDER PROTECTION

452809550

—

11

FRAME SYSTEM

452814437

—

12

SUSPENSION SYSTEM

452901431

—

13

FRONT AXLE SYSTEM

453007001

—

14

WHEEL AND HUB SYSTEM

453102149

—

15

STEERING SYSTEM

453407539

—

16

BRAKE SYSTEM CONFIGURATION

AIRBAG SEAT (MIDDLE TOP + SPIRAL SPRING MOUNT + AIRBAG SEAT)

453519632

—

17

ELECTRICAL SYSTEM ORDINARY 165 BATTERY

MANUAL DOOR + NORMAL + MANUAL

453708856

—

18

INSTRUMENT SYSTEM

453802533

—

19

HARNESS SYSTEM

MIDDLE ROOF

454007147

—

20

LAMP SYSTEM

(HALOGEN MANUAL + FOG LAMP)

454100763

—

21

SEMI-FLOATING CAB SUSPENSION-MANUAL LIFT + SINGLE CYLINDER

455006853

—

22

CAB WELDING ASSEMBLY-RIGHT-DRIVE SINGLE-ROW MANUAL TRANSMISSION

455017494

—

23

FLOOR COVERING ASSEMBLY

455102294

—

24

FLOOR INSULATION BOARD ASSEMBLY - MECHANICAL THROTTLE PEDAL +SINGLE COOLER

455106484

—

25

LOWER BODY GUARD ASSEMBLY

455102240

—

26

WINDSHIELD - NO HEAD UP DISPLAY

455200308

—

27

FRONT WALL COVER ASSEMBLY

455302659

—

28

DASHBOARD GLOVE BOX ASSEMBLY

455302636

—

29

INSTRUMENT PANEL TUYERE ASSEMBLY

455302637

—

30

ASSISTANT INSTRUMENT PANEL ASSEMBLY-WEICHAI+DUMP TRUCK

455302660

—

31

DASHBOARD ASSEMBLY - NO MULTIMEDIA

455302645

—

32

SIDE ENCLOSURE COVER ASSEMBLY-NO DEBRIS BOX

455400953

—

33

BLOCKING COVER ASSEMBLY

455500237

—

34

REAR WALL COVER ASSEMBLY - WITH REAR WINDOW MIDDLE ROOF

455600889

—

35

REAR WINDSHIELD ASSEMBLY

455600828

—

36

MIDDLE ROOF REAR ENCLOSURE COVER ASSEMBLY-WITHOUT DEFLECTOR

455601130

—

37

TOP COVER PROTECTION ASSEMBLY

455701681

—

38

SUNSHADE ASSEMBLY-LEFT RUDDER OUTLET CAR ROOF

455701421

—

39

LUGGAGE RACK ASSEMBLY-RETRACTABLE MACHINE

455701447

—

40

CEILING INSULATION PAD ASSEMBLY

455701396

—

41

MANUAL WINDOW REGULATOR MANUAL DOOR

456101455

—

42

DOOR WINDOW SYSTEM

456101284

—

43

DOOR WINDOW REGULATOR ASSEMBLY MANUAL DOOR LOCK MANUAL DOOR

456101292

—

44

DOOR LOCK ASSEMBLY-MANUAL DOOR LOCK MANUAL DOOR

456101293

—

45

DOOR HINGE ASSEMBLY

456101303

—

46

DOOR SEAL ASSEMBLY

456101306

—

47

DOOR STOPPER ASSEMBLY

456101309

—

48

MAIN DRIVE SEAT - AIR BAG SEAT AND VELVET SEAT

456800283

—

49

FIRST OFFICER SEAT - VELVET SEAT

456900119

—

50

LOWER SLEEPER COMPARTMENT FRAME ASSEMBLY

457600263

—

51

SLEEPER CUSHION ASSEMBLY - VELVET SLEEPER

457600264

—

52

SOUND SYSTEM (RECEIVER)

NORMAL STEERING WHEEL

457900020

—

53

AIR CONDITIONING SYSTEM

458105831

—

54

REARVIEW MIRROR AND BLIND MIRROR ASSEMBLY-MECHANICAL REARVIEW MIRROR

458200891

—

55

LEFT SUN SHADE ASSEMBLY

458200740

—

56

MIDDLE HANDLE ASSEMBLY

458200864

—

57

LOWER VIEW MIRROR ASSEMBLY

458200895

—

58

FRONT WHEEL EYEBROW ASSEMBLY

458401992

—

59

FRONT WHEEL MUDGUARD ASSEMBLY-WITH SPLASH GUARD

458402105

—

60

FRONT STEP ASSEMBLY-ENGINEERING VIHICLE

458402018

—

Каталог запасных частей к технике: XCMG XGA3250d2WC. 450001992 WAFH641R DUMP TRUCK
