1

BRACKET OF HYDRAULIC CYLINDER

455016348

—

2

PIPE ASSEMBLY - HYDRAULIC CYLINDER TO TRANSITION BRACKET

455017438

—

3

PIPE ASSEMBLY - HYDRAULIC CYLINDER TO TRANSITION BRACKET

455017438

—

4

PIPE GUIDE BRACKET

455017563

—

5

JOINTS

Q81306

805805963

—

6

TEE JOINT

455003023

—

7

HEXAGON FLANGE FACE BOLT

Q1850825

805050226

—

8

PIPE ASSEMBLY - TEE TO HYDRAULIC LOCK

455017562

—

9

I-NUTS

Q381B20T13F2

805239383

—

10

HEXAGONAL SOCKET FLANGE FACE BOLT-FINE THREAD

Q1851250

805050299

—

11

HEXAGONAL SOCKET THIN NUT

Q351B12

805239613

—

12

GASKET

455001758

—

13

PINS

805639727

—

14

MANUAL HYDRAULIC CYLINDER ASSEMBLY

455010309

—

15

INNER SLEEVE

455003041

—

16

WASHER14

805339068

—

17

WASHER14

805339110

—

18

INNER SLEEVE

455002923

—

19

TYPE 1 HEXAGON SLOTTED NUT

Q381B14T13F2

805239379

—

20

PINS

Q5003232

805639724

—

21

HEXAGONAL SOCKET FLANGE FACE NUT

Q32312

805239535

—

22

BIG WASHER

Q40220

805339093

—

23

SCREW - LOWER BRACKET

455002782

—

24

PIPE ASSEMBLY - TEE TO HYDRAULIC LOCK

455017558

—

25

HEXAGONAL SOCKET FLANGE FACE BOLT

805051327

—

26

SINGLE TUBE CLAMPD14

Q68614F4

805805903

—

27

TUBE ASSEMBLY - HYDRAULIC PUMP TO TRANSITION BRACKET (OIL RETURN)

455017564

—

28

TUBE ASSEMBLY - HYDRAULIC PUMP TO TEE

455017561

—

29

TUBE ASSEMBLY - HYDRAULIC PUMP TO TRANSITION BRACKET (OIL IN)

455017560

—

30

MULTI-PIPE CLAMP

Q687063

805805913

—

31

HEXAGONAL SOCKET HEAD BOLT AND FLAT WASHER ASSEMBLY

Q140B0412

805049772

—

32

NUTM6

860141641

—

33

PIPE FIXING CLIPS

455016808

—

34

FLAT WASHER

Q401B06

860141640

—

35

WASHER6

860141801

—

36

HEXAGONAL SOCKET HEAD BOLT

860141800

—

37

HEXAGON FLANGE FACE BOLT

Q1840825

805050104

—

38

MANUAL HYDRAULIC PUMP ASSEMBLY

455003045

—

39

COMPRESSIVE BAR

455002573

—

Каталог запасных частей к технике: XCMG XG90H. 455017559 CAB FLIP MECHANISM
