Каталог запасных частей к технике: XCMG XG90H. 453529390 XGA35DFWD35-11100

← 453529372 XGA35DFWD35-11200 453529388 AXLE BRAKING SYSTEM →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

HEXAGON FLANGE BOLTS-FINE PITCH

Q1850820

805050224

—

PIPING BRACKET

453500770

—

INSULATION SLEEVE (OPENING)

453403658

—

HEXAGONAL SOCKET HEAD SCREW PLUG

Q617B12

803417096

—

FERRULE TAPERED THREAD RIGHT-ANGLE CONNECTOR

Q80806

805805955

—

STRAIGHT PIPE JOINT

END THROUGH CONNECTOR BODY M12Ч1.5/G5

453502445

—

SINGLE TUBE CLAMP

453501003

—

HEXAGONAL SOCKET FLANGE FACE BOLT

Q1850620

805050215

—

SINGLE PIPE CLIP

Q68605F4

805805896

—

ELBOW

BENT CONNECTOR BODY M12Ч1.5/G5

453501585

—

COMPRESSION NUT

GLAND NUTM12Ч1.5

453503637

—

SEALING WASHER

Q72312T3

805339152

—

JOINTS

Q80805

805805954

—

ELBOW

BENT CONNECTOR BODY M12Ч1.5/G10

453500169

—

ELBOW

BENT CONNECTOR BODY M16Ч1.5/G12

453502164

—

HYDRAULICALLY OPERATED O-TYPE RUBBER SEAL RING

Q734B1400265

805805925

—

HYDRAULICALLY OPERATED O-TYPE RUBBER SEALING RING

Q734B1000265

805805924

—

GLAND NUT

GLAND NUT M16 X 1.5+ THICKNESS 10

453502155

—

ELBOW

BENT CONNECTOR BODY M12Ч1.5/G6

453505135

—

−
