266135108202

OIL SLINGER

266135108202

—

9976747

OIL SEAL, HUB OUTER (SINGLE LIP)

9976747

—

14580611002

INTERNAL CIRCLIP 110X4

14580611002

—

264342309901

POLE WHEEL REAR

264342309901

—

264342303302

SENSOR MTG. BRACKET (REAR) - ABS

OPTIONAL

264342303302

—

264342303303

SENSOR MTG. BRACKET (REAR) - ABS

OPTIONAL

264342303303

—

263242103403

SENSOR BUSH -ABS

263242103403

—

264354209929

SENSOR -`L TYPE' (WHEEL SPEED) .

264354209929

—

261235308201

LOCKING PLATE

261235308201

—

266135306101

LOCKING PLATE (DIFFERENTIAL CASE)

266135306101

—

266135308004

HEX. SCREW

266135308004

—

266135307801

DUST SEAL

266135307801

—

266135300125

DIFFERENTIAL GEAR AND SPIDER KIT CONSISTS OF:

266135300125

—

1

ASSY. REAR AXLE COMPLETE WITH BRAKE ( 28/9 CWP RATIO ) WITH ABS

266135000140

—

4

ASSY. REAR AXLE HOUSING WITH SUPPORTING TUBES, WITH ABS

266135100139

—

18

SPACER

261235608601

—

19

LOCKING RING

261235606501

—

20

LOCKING PLATE

261235608202

—

21

ASSY. BREATHER

257433150102

—

22

HUB PIN REAR

282140106701

—

23

STUD M16

266535608801

—

25

HEX NUT M12X1.5

12302696029

—

28

OIL CATCHER, (FOR ABS)

266135608201

—

29

PRESSURE RING

266135108602

—

30

OIL SEAL, HUB INNER (DOUBLE LIP)

266135607701

—

31

SPACER

266135608601

—

33

TAPER ROLLER BEARING, INNER

257535603110

—

34

SHIM-0.05 THK.

FOR SELECTION, AR

266135608301

—

34

SHIM-0.10 THK.

FOR SELECTION, AR

266135608302

—

34

SHIM-0.15 THK.

FOR SELECTION, AR

266135608303

—

34

SHIM-0.20 THK.

FOR SELECTION, AR

266135608304

—

34

SHIM-0.25 THK.

FOR SELECTION, AR

266135608305

—

34

SHIM-0.30 THK.

FOR SELECTION, AR

266135608306

—

34

SHIM-0.50 THK.

FOR SELECTION, AR

266135608307

—

34

SHIM-1.00 THK.

FOR SELECTION, AR

266135608308

—

34

SHIM-1.50 THK.

FOR SELECTION, AR

266135608309

—

34

SHIM-2.5 THK.

FOR SELECTION, AR

266135608310

—

36

TAPER ROLLER BEARING, OUTER

261235603102

—

37

SPACER TUBE

266135608602

—

38

ASSY.REAR HUB (FOR ABS)

266135600118

—

39

BRAKE DRUM

264142103701

—

40

REAR AXLE SHAFT

266135707902

—

41

GASKET (FOR BRAKE DRUM WITH HUB)

266135605302

—

42

MAGNETIC DRAIN PLUG

266335107201

—

43

SCREW PLUG OIL FILLING

9970506

—

47

THREADED RING

266135306501

—

48

LOCKING PLATE

3129941201

—

49

LOCKING PLATE

261235608202

—

50

HEX. SCREW M 8X12

11323996191

—

52

ADJUSTING PIN

261235300103

—

53

HEX. THIN NUT M 18X1.5

12080901800

—

58

GASKET (BETWEEN R.A. HOUSING & REAR COVER)

266135105301

—

59

ASSY. COVER REAR AXLE HOUSING

266135100105

—

60

SPRING WASHER B 10

12520698050

—

61

HEX. SCREW M 10X18

11323998185

—

71

DIFFERENTIAL HOUSING ASSY.

266135300121

—

76

DIFFERENTIAL SPIDER

SERVICED AS A SET

266135305103

—

76

DIFFERENTIAL SPIDER

—

78

DIFFERENTIAL BEVEL PINION

SERVICED AS A SET

266135305419

—

78

BEVEL GEAR

—

79

SPHERICAL WASHER (STEEL)

266135309210

—

81

REAR AXLE SHAFT GEAR

SERVICED AS A SET

266135305420

—

81

GEAR R.A SHAFT

—

82

THRUST WASHER, SHAFT GEAR 1.95 MM

OPTIONAL

266135309202

—

82

THRUST WASHER, SHAFT GEAR 2.00 MM

OPTIONAL

266135309203

—

82

THRUST WASHER, SHAFT GEAR 2.05 MM

OPTIONAL

266135309204

—

82

THRUST WASHER, SHAFT GEAR 2.10 MM

OPTIONAL

266135309205

—

82

THRUST WASHER, SHAFT GEAR 2.15 MM

OPTIONAL

266135309206

—

82

THRUST WASHER, SHAFT GEAR 2.20 MM

OPTIONAL

266135309207

—

82

THRUST WASHER, SHAFT GEAR 2.25 MM

OPTIONAL

266135309208

—

85

TAPER ROLLER BEARING (55X100X26.75)

261235303101

—

87

SET CROWN WHEEL AND PINION (31/8 RATIO)

266135300119

—

92

CYLINDRICAL ROLLER BRG. (PINION NOSE)

266135303116

—

99

TAPER ROLLER BRG. (TAIL PINION)

266135303105

—

104

SPACER (BETWEEN TAIL PINION BRGS.)

266135308632

—

105

THREADED RING

266135306501

—

106

SPACER (BETWEEN BRG. AND FLANGE)

266135308668

—

111

OIL SEAL TAIL PINION

266135307702

—

112

SHIM 0.15 THICK

FOR SELECTION, AR

266135308303

—

112

SHIM 0.20 THICK

FOR SELECTION, AR

266135308304

—

112

SHIM 0.25 THICK

FOR SELECTION, AR

266135308305

—

112

SHIM 0.30 THICK

FOR SELECTION, AR

266135308306

—

112

SHIM 0.45 THICK

FOR SELECTION, AR

266135308307

—

112

SHIM 0.50 THICK

FOR SELECTION, AR

266135308308

—

112

SHIM 1.0 THICK

FOR SELECTION, AR

266135308309

—

112

SHIM 1.5 THICK

FOR SELECTION, AR

266135308310

—

115

SPACER RING, TAIL PINION 7.64 THICK

FOR SELECTION

266135308637

—

115

SPACER RING, TAIL PINION 7.66 THICK

FOR SELECTION

266135308638

—

115

SPACER RING, TAIL PINION 7.68 THICK

FOR SELECTION

266135308639

—

115

SPACER RING, TAIL PINION 7.72 THICK

FOR SELECTION

266135308641

—

115

SPACER RING, TAIL PINION 7.74 THICK

FOR SELECTION

266135308642

—

115

SPACER RING, TAIL PINION 7.78 THICK

FOR SELECTION

266135308644

—

115

SPACER RING, TAIL PINION 7.82 THICK

FOR SELECTION

266135308646

—

115

SPACER RING, TAIL PINION 7.84 THICK

FOR SELECTION

266135308647

—

115

SPACER RING, TAIL PINION 7.86 THICK

FOR SELECTION

266135308648

—

115

SPACER RING, TAIL PINION 7.88 THICK

FOR SELECTION

266135308649

—

115

SPACER RING, TAIL PINION 7.90 THICK

FOR SELECTION

266135308650

—

115

SPACER RING, TAIL PINION 7.92 THICK

FOR SELECTION

266135308651

—

115

SPACER RING, TAIL PINION 7.94 THICK

FOR SELECTION

266135308652

—

115

SPACER RING, TAIL PINION 7.96 THICK

FOR SELECTION

266135308653

—

115

SPACER RING, TAIL PINION 7.98 THICK

FOR SELECTION

266135308654

—

115

SPACER RING, TAIL PINION 8.00 THICK

FOR SELECTION

266135308655

—

115

SPACER RING, TAIL PINION 8.02 THICK

FOR SELECTION

266135308656

—

115

SPACER RING, TAIL PINION 8.04 THICK

FOR SELECTION

266135308657

—

115

SPACER RING, TAIL PINION 8.06 THICK

FOR SELECTION

266135308658

—

115

SPACER RING, TAIL PINION 8.08 THICK

FOR SELECTION

266135308659

—

115

SPACER RING, TAIL PINION 8.10 THICK

FOR SELECTION

266135308660

—

115

SPACER RING, TAIL PINION 8.12 THICK

FOR SELECTION

266135308663

—

115

SPACER RING, TAIL PINION 8.14 THICK

FOR SELECTION

266135308664

—

115

SPACER RING, TAIL PINION 8.16 THICK

FOR SELECTION

266135308665

—

115

SPACER RING, TAIL PINION 8.18 THICK

FOR SELECTION

266135308666

—

115

SPACER RING, TAIL PINION 8.20 THICK

FOR SELECTION

266135308667

—

118

COUPLING FLANGE

266135305001

—

119

DUST COVER

266135308203

—

120

HEX. NUT (TAIL PINION COUPLING FLANGE)

266135306504

—

124

ASSY. BRAKE CHAMBER MOUNTING BRACKET RH

264142310126

—

124

ASSY. BRAKE CHAMBER MOUNTING BRACKET LH

264142310130

—

Каталог запасных частей к технике: Tata LPT 613 LHD EURO II. REAR AXLE
