1

MAIN SHAFT (6 SPEED)

269126207911

—

2

2ND SPEED GEAR[M/SHAFT](LOOSESYN.RING)

269126205437

—

3

NEEDLE CAGE DOUBLE ROW

269126203120

—

4

ENGAGING GEAR(1ST/2ND) LOOSE SYN.RING.

269126204641

—

5

SYNCHROCONE (1/2 -3/4) (CARBON)

269126204650

—

5

SYNCHROCONE (1/2 -3/4) (CARBON)

269126204650

—

6

COMPRESSION SPRING

250726208705

—

6

COMPRESSION SPRING

250726208705

—

7

RETENTION PIN

250726206702

—

7

RETENTION PIN

250726206702

—

8

SHIFTER SLEEVE (1ST / 2ND / 3RD / 4TH)

269126204618

—

8

SHIFTER SLEEVE (1ST / 2ND / 3RD / 4TH)

269126204618

—

9

CIRCLIP (2.3 THICK)

FOR SELECTION

269126204313

—

9

CIRCLIP (2.4 THICK)

FOR SELECTION

269126204314

—

9

CIRCLIP (2.6 THICK)

FOR SELECTION

269126204315

—

9

CIRCLIP (2.6 THICK)

FOR SELECTION

269126204316

—

9

CIRCLIP (2.7 THICK)

FOR SELECTION

269126204317

—

12

1ST SPEED GEAR[M/SHAFT](LOOSE SYN.RING)

269126205436

—

13

NEEDLE CAGE 1ST SPEED

269126203111

—

15

ENGAGING GEAR (REVERSE)

269126204616

—

16

CIRCLIP (1.8 THICK)

FOR SELECTION

269126204301

—

16

CIRCLIP (1.9 THICK)

FOR SELECTION

269126204302

—

16

CIRCLIP (2.1 THICK)

FOR SELECTION

269126204304

—

16

CIRCLIP (2.2 THICK)

FOR SELECTION

269126204305

—

16

CIRCLIP (2.3 THICK)

FOR SELECTION

269126204310

—

16

CIRCLIP (2.4 THICK)

FOR SELECTION

269126204311

—

16

CIRCLIP (2.0 THICK)

FOR SELECTION

269126204303

—

16

CIRCLIP (1.8 THICK)

FOR SELECTION

269126204301

—

16

CIRCLIP (1.9 THICK)

FOR SELECTION

269126204302

—

16

CIRCLIP (2.0 THICK)

FOR SELECTION

269126204303

—

16

CIRCLIP (2.1 THICK)

FOR SELECTION

269126204304

—

16

CIRCLIP (2.2 THICK)

FOR SELECTION

269126204305

—

16

CIRCLIP (2.3 THICK)

FOR SELECTION

269126204310

—

16

CIRCLIP (2.4 THICK)

FOR SELECTION

269126204311

—

17

NEEDLE CAGE (REVERSE / 4TH GEAR)

269126203106

—

17

NEEDLE CAGE (REVERSE / 4TH GEAR)

269126203106

—

18

REVERSE GEAR (MAIN SHAFT)

269126205413

—

19

SPACER (MAIN SHAFT) (11.2 THICK)

FOR SELECTION

269126208614

—

19

SPACER (MAIN SHAFT) (11.4 THICK)

FOR SELECTION

269126208612

—

19

SPACER (MAIN SHAFT) (11.3 THICK)

FOR SELECTION

269126208613

—

19

SPACER (MAIN SHAFT) (10.4 THICK)

FOR SELECTION

269126208627

—

19

SPACER (MAIN SHAFT) (10.5 THICK)

FOR SELECTION

269126208626

—

19

SPACER (MAIN SHAFT) (11.5 THICK)

FOR SELECTION

269126208625

—

19

SPACER (MAIN SHAFT) (11.6 THICK)

FOR SELECTION

269126208624

—

19

SPACER (MAIN SHAFT) (10.5 THICK)

FOR SELECTION

269126208620

—

19

SPACER (MAIN SHAFT) (10.7 THICK)

FOR SELECTION

269126208619

—

19

SPACER (MAIN SHAFT) (10.8 THICK)

FOR SELECTION

269126208618

—

19

SPACER (MAIN SHAFT) (10.9 THICK)

FOR SELECTION

269126208617

—

19

SPACER (MAIN SHAFT) (11.0 THICK)

FOR SELECTION

269126208616

—

19

SPACER (MAIN SHAFT) (11.1 THICK)

FOR SELECTION

269126208615

—

20

TAPER ROLLER BEARING (CLUTCH SIDE)

269126203103

—

23

SPEEDO GEAR (MAIN SHAFT)

268826205407

—

24

SPACER (COUPLING FLANGE)

269126208601

—

25

OIL SEAL (MAIN SHAFT)

269126207814

—

29

ASSY. COUPLING FLANGE

269126200173

—

30

LOCK NUT (COUPLING FLANGE)

268826206501

—

33

3RD SPEED GEAR[M/SHAFT](LOOSE SYN.RING)

269126205438

—

34

NEEDLE CAGE (1ST / 2ND / 3RD GEAR)

269126203124

—

35

ENGAGING GEAR(3RD/4TH) LOOSE SYN.RING.

269126204642

—

41

4TH SPEED GEAR(6.58 RATIO-LOOSE SYNRING)

FOR 6.58 RATIO

269126205442

—

42

SPACER (MAIN SHAFT)

269126208628

—

43

CIRCLIP (2.4 THICK)

FOR SELECTION

269126204306

—

43

CIRCLIP (2.5 THICK)

FOR SELECTION

269126204307

—

43

CIRCLIP (2.6 THICK)

FOR SELECTION

269126204308

—

43

CIRCLIP (2.7 THICK)

FOR SELECTION

269126204309

—

43

CIRCLIP (2.8 THICK)

FOR SELECTION

269126204312

—

46

ASSY ENGAGING GEAR(5TH/DS)

269126200171

—

47

NEEDLE CAGE

269126203105

—

48

SYNCHRO CONE (5 / 6 CARBON)

269126204651

—

49

ENGAGING GEAR (5TH / 6TH SPEED)

269126204640

—

51

CARRIER

268826209901

—

52

COMPRESSION SPRING

3219930701

—

53

RETENTION PIN (3/4)

268826206702

—

55

SHIFTER SLEEVE (5TH / 6TH SPEED)

268826204608

—

56

CIRCLIP 2.5 THICK

FOR SELECTION

251526204312

—

56

CIRCLIP 2.54 THICK

FOR SELECTION

251526204313

—

56

CIRCLIP 2.58 THICK

FOR SELECTION

251526204314

—

56

CIRCLIP 2.62 THICK

FOR SELECTION

251526204315

—

56

CIRCLIP 2.66 THICK

FOR SELECTION

251526204316

—

56

CIRCLIP 2.7 THICK

FOR SELECTION

251526204333

—

56

CIRCLIP 2.8 THICK

FOR SELECTION

251526204334

—

56

CIRCLIP 2.75 THICK

FOR SELECTION

251526204335

—

58

ROLLER (FOR DRIVE SHAFT)

269126253113

—

Каталог запасных частей к технике: Tata LPT 1618 TC/52. MAIN SHAFT AND GEAR
