1

Plate

27150110571

—

2

Block

27150108321

—

3

Bolt gb16674-m10x95epzn-8.8

4011000316

—

4

Nut gb6185-m10epzn-8

4013010119

—

5

Plate

27150115981

—

6

Bolt gb5783-m10x30epzn-8.8

4011000084

—

7

Washer gb97.1-10epzn-300hv

4015000162

—

8

Nut gb6170-m10epzn-8

4013000007

—

9

Steering gear assembly

27150119571

—

10

Bolt gb16674.1-m10x25epzn-8.8

4011000474

—

11

Flange fittings

27150109871

—

12

O-ring gb3452.1-37.5x3.55g

4030000029

—

13

Flange lgb117312551

4041000027

—

14

Bolt gb16674-m10x30epzn-8.8

4011000475

—

15

Washer gb97.1-12epzn-300hv

4015000168

—

16

Nut gb6170-m12 epzn-8

4013000011

—

17

Plate

27150109921

—

18

Bolt gb5782-m10x45epzn-8.8

4011000451

—

19

Hose assembly

27150111621

—

20

Priority valve assembly

27150119911

—

21

Washer 16

27150105312

—

22

Bolt gb5783-m16x45flznyc-12.9-480

4011010621

—

23

Hose lgb128-006171

4041010532

—

24

Hose lgb165-014260

4041000786

—

25

Bolt gb5783-m10x45epzn-8.8

4011000514

—

26

Nut gb6185-m16epzn-88

4013010122

—

27

Washer gb97.1-16epzn-300hv

4015000181

—

28

Bolt gb5782-m12x100epzn-8.8

4011000335

—

29

O-ring gb3452.1-60.0x3.55g

4030000164

—

30

O-ring lgb168-12931

4041000765

—

31

Assembly

27150121101

—

32

Assembly

27150121081

—

33

Clamp jb8870-d90

4017000013

—

34

Hose lgb127-010144

4041010531

—

35

Clapboard joint

27150109051

—

36

Nut

27150102951

—

37

Plate

27150111661

—

38

Bolt gb5782-m16x120flznyc-10.9

4011010591

—

39

Hose lgb128-006082

4041010359

—

40

Hose lgb128-003190

4041010373

—

41

Bracket

27150110161

—

42

Connector lgb143-01406

4041001047

—

43

Pipe lgb127-006075

4041000699

—

44

Plate

27150111481

—

45

Plate

27150111491

—

46

Plate

27150111501

—

47

Shaft

27150106671

—

48

Steering cylinder base

27150110001

—

49

Nipple

27150108001

—

50

Plug 4bn-04wd

4190001419

—

51

Built-up joint lgb143-02616

4041001006

—

52

Hose

4041000929

—

53

Grease cup jb7940.1-m10x1

4030000065

—

54

Grease nozzle protective cap

4120000015

—

55

Axis

27150109901

—

56

Sleeve

27150109951

—

57

Bolt gb5783-m12x30epzn-8.8

4011000197

—

58

Washer gb1230-12epzn-45

4015000288

—

59

Steering cylinder hsgl-80x45x390-700

4120001483

—

60

Axis

27150110951

—

61

Combi nipple lgb143-03625

4041001211

—

62

Pump jhp2080r04

4120709561

—

63

Gasket

29110000043

—

64

Bolt gb5783-m12x35flznyc-12.9-480

4011010579

—

65

Screw gb70.1-m8x25epzn-12.9

4014010141

—

66

Transition flange

27150113721

—

67

Joint lgb120-01414

4041000133

—

68

O-ring lgb168-11124

4041000767

—

69

Connecter

4041001040

—

70

O-ring 28.0x2.65g

4030000090

—

71

Welding

27150121141

—

72

O-ring gb3452.1-47.5x3.55g

4030000130

—

73

Flange lgb117-314651

4041000010

—

74

Bolt gb16674-m12x35epzn-8.8

4011000477

—

75

Hydraulic oil tank bracket assembly

27160108901

—

76

Bolt gb5782-m16x50epzn-8.8

4011000510

—

77

Plate

27150109961

—

78

Rubber clip

27150109981

—

79

Rubber clip

27150109992

—

80

Bolt gb5782-m10x100epzn-8.8

4011000817

—

81

Hose lgb128-006092

4041010356

—

82

Steering column

4120002387

—

83

Check valve b-sy-rv-l18-jm33x2-0.5

4120709260

—

84

Hose lgb128-006175

4041010533

—

85

Joint lgb143-12616

4041001417

—

86

Bolt gb5783-m10x50epzn-8.8

4011000489

—

87

Bolt gb5782-m16x110flznyc-12.9-480

4011010564

—

88

O-ring gb3452.1-19.0x2.65g

4030000280

—

89

Straight joint lgb155-01822

4041000822

—

90

Welding

27150121021

—

91

Tee fitting bc-22

4190000985

—

92

Connecter lgb143-12213

4041001218

—

93

Hose lgb165-010440

4041010374

—

94

Hose lgb165-003300

4041010206

—

95

Hose lgb129-006075

4041010357

—

96

Hose lgb129-006050

4041010352

—

97

Screw gb818-m5x16epzn-4.8

4014000088

—

98

Nut gb6185-m16flznyc-12-480

4013010251

—

99

Bolt gb5783-m12x50epzn-8.8

4011000092

—

100

Combination joint lgb143-02213

4041001156

—

101

Plate

27150121051

—

102

Hydraulic oil tank assembly

27160113192

—

103

Rubber sheath

4120002400

—

104

Tube

27160109731

—

105

Steering wheel-430

4120001247

—

106

Lh lower housing

4120002401

—

107

Rh lower housing

4120002402

—

108

Hose clamp jb8870-d80

4017000014

—

109

Block assembly

27150107961

—

Каталог запасных частей к технике: LGMG CMS50. Steering assembly
