Каталог запасных частей к технике: FAW CA3256 (NewJ5P) (P2K2T1EYA81). Main Reductor Assembly

Каталог запасных частей к технике: FAW CA3256 (NewJ5P) (P2K2T1EYA81). Main Reductor Assembly

← Brake Assembly Differential Control Pipeline Module →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

1

Flange Nut

W2402071F01C

—

—

—

2

Flange Assy

LC300 flange assembly (8 holes)

W2402060F01C

—

—

—

3

Seal, Oil

LC300 reduction gear oil seal

W2402050F01C

—

—

—

4

Bearing

31313 bearing (485/LC bearing housing)

31313

—

—

—

5

Bearing Seat

LC300 bearing housing

W2402041F01C

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.25)

2402181D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.275)

2402182D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.35)

2402183D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.375)

2402184D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.45)

2402185D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.475)

2402186D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.55)

2402187D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.575)

2402188D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.65)

2402189D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.675)

2402190D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.75)

2402191D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.775)

2402192D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.85)

2402193D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.875)

2402194D1H

—

—

—

6

Adjusting Shim-Drive Bevel Gear Bearing

Adjusting shims - Drive bevel gear bearing (3.9) (81-

2402195D1H

—

—

—

7

Spacer Pipe

LC300 Spacer Tube - Rear Reduction

W2402042F01C

—

—

—

7

Spacer Pipe

LC300 Spacer Tube - Rear Reduction

W2402043F01C

—

—

—

8

Bearing

LC300 Bearing (Reduction)

32314B (T5GD070)

—

—

—

9

Drive\Driven Cone Gear

LC300 Main and Driven Bevel Gear Pair (5.921) Rear Axle

W2402030F01B

—

—

—

10

Hexagon Head Bolt-Thin Tooth

Q151B1440TF2

—

—

—

11

Bolt

W2402011F01C

—

—

—

12

Locking Bolt

W2402012F01C

—

—

—

13

Intershaft Differtial Locking Sub Assy

Z2406010F01C-F

—

—

—

14

Main Reductor HousingAssy

Z2402020F01C

—

—

—

15

Cone Gear Differential Bearing Cover

Z2402022F01D-10

—

—

—

16

Locking Bolt

W2402024F01C

—

—

—

17

Cylindrical Pin

Q5210820

—

—

—

18

Sliding GearSleeve

W2407016F01C

—

—

—

19

Fixing Meshing Bush

W2407017F01C

—

—

—

20

Adjusting Ring

W2403078F01C

—

—

—

22

Bolt

W2403024F01C

—

—

—

24

Differential Housing (Lh)

W2403021F01C-20

—

—

—

28

Planetary Gear Assembly

W2403050F01C

—

—

—

28-1

Planet Gear Washer

W2403054F01C

—

—

—

30

Spacer Ring

W2403055F01C

—

—

—

31

Cross Shaft

W2403056F01C

—

—

—

34

Differential Housing (Rh)

W2403022F01C-20

—

—

—

36

Seal, Oil

W2403073F01C

—

—

—

37

Bearing Shield

W2403072F01C

—

—

—

38

Adjusting Nut

W2403071F01C

—

—

—

39

Bearing Shield

W2402044F01C

—

—

—

21

Bearing

33115 (3007715)

—

—

—

35

Bearing

33115 (3007715)

—

—

—

26

Half-Axle Gear Washer

W2403052F01C

—

—

—

33

Half-Axle Gear Washer

W2403052F01C

—

—

—

26

Half-Axle Gear Washer

W2403058F01C

—

—

—

33

Half-Axle Gear Washer

W2403058F01C

—

—

—

26

Half-Axle Gear Washer

W2403059F01C

—

—

—

33

Half-Axle Gear Washer

W2403059F01C

—

—

—

26

Half-Axle Gear Washer

W2403059F01C

—

—

—

33

Half-Axle Gear Washer

W2403059F01C

—

—

—

26

Half-Axle Gear Washer

W2403059F01C

—

—

—

33

Half-Axle Gear Washer

W2403059F01C

—

—

—

26

Half-Axle Gear Washer

W2403060F01C

—

—

—

33

Half-Axle Gear Washer

W2403060F01C

—

—

—

27

Axle Shaft Gear

LC300 Half-Shaft Gear

W2403051F01C

—

—

—

32

Axle Shaft Gear

LC300 Half-Shaft Gear

W2403051F01C

—

—

—

W2403020F01C

Differential House Assy

LC300 Differential Housing Assembly

W2403020F01C

—

—

—

W2506053F01C

Gasket

Gasket - Differential Lock

W2506053F01C

—

—

—

Z2403010F01C

DifferentialAssembly

LC300 Differential Assembly (6.733/5.921/5.26)

Z2403010F01C

—

—

—

−
