Каталог запасных частей к технике: FAW CA3250. Relay valve logic assembly (rear driving)

← Air Handling Unit Assembly Relay Valve Assembly (Parking) →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Bracket-Double Relay Valve

3518012-Q3653

—

Болт

CQ1501025

—

Пружинная шайба

Q40310

—

Гайка

CQ34010

—

Пружинная шайба

Q40308

—

Гайка

CQ34008

—

Double Relay Valve Assembly

3518900-Q3904WA

—

Relay Valve with Pipe Connector Assembly

3518010-Q3904WA

—

Circlip (d12)

3513407-1500

—

Threaded Sleeve (M22) With Seal Ring Assy

3513410-1500

—

Special Shaped Seal Ring (d15.2)

3513403-1500

—

Relay Valve Assembly

3518015-50AWA

—

Pressing Plate Nut

3518035-DX802

—

Gasket

3518025-DX802

—

O-ring (ф 22)

3518403-DX802

—

Threaded Sleeve (M16) With Seal Ring Assy

3506410-1500

—

Special Shaped Seal Ring (d9.7)

3506403-1500

—

Circlip (d10)

3506407-1500

—

Brake Valve Connector

3522010-Q818

—

Relay Valve With Fast Plug Connector Assembly

3518030-Q3904WA

—

−

40%

Relay valve logic assembly (rear driving)
