Каталог запасных частей к технике: DongFeng L3251A3 (вар.). Rear Axle Main Retarder Assembly

Каталог запасных частей к технике: DongFeng L3251A3 (вар.). Rear Axle Main Retarder Assembly

← Rear Axle Case Subassembly Rear Left Brake Subassembly →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Q151B1490-0H1-J1

Hexagon Bolt

Q151B1490-0H1-J1

—

—

—

2402ZHS01-384

Retaining Plate Differential Bearing Cover

2402ZHS01-384

—

—

—

32216-1

Bearing Outer Race

Wear Part, To be Used Together with Outer Race

32216-1

—

—

—

Q150B0815

Болт

Q150B0815

—

—

—

2402ZHS01-382

Adjusting Nut Differential Bearing

2402ZHS01-382

—

—

—

Q40308

Пружинная шайба

Q40308

—

—

—

Q151B1445-0H1-J1

Болт

Q151B1445-0H1-J1

—

—

—

Q40514

Тяжелая пружинная шайба

Q40514

—

—

—

Q151B1445-0H1-J1

Болт

Q151B1445-0H1-J1

—

—

—

Q40514

Тяжелая пружинная шайба

Q40514

—

—

—

Q151B1445-0H1-J1

Болт

Q151B1445-0H1-J1

—

—

—

Q40314

Пружинная шайба

Q40314

—

—

—

Q341B14

Гайка

Q341B14

—

—

—

Q151B1460

Hexagon Bolt

Q151B1460

—

—

—

Q40514

Тяжелая пружинная шайба

Q40514

—

—

—

Q5220820

Straight Pin

Q5220820

—

—

—

2402010-T1700

Rear Axle Main Retarder and Bevel Gear Differential Assembly

2402010-T1700

—

—

—

1

Nut

2402ZHS01-072

—

—

—

2

Washer

2402ZHS01-071

—

—

—

3

Flange Assembly

2402ZHS01-065

—

—

—

4

O Ring

2402ZHS01-069-A

—

—

—

5

Oil Seal Assembly

Wear Part

2402ZHS01-060

—

—

—

6

Bearing Seat

2402ZHS01-036

—

—

—

7

O Ring

Wear Part

2402ZHS01-069-A

—

—

—

8

Bevel Bearing - Driving Bevel Gear

Wear Part

27314E

—

—

—

9

Tapered Roller Bearing

Wear Part

32315

—

—

—

10

Adjusting Nut - Differential Bearing

2402ZHS01-381

—

—

—

11

Bearing Inner Race Assembly

Wear Part, To be Used Together with Inner Race

32216-2

—

—

—

12

Bolt - Driven Bevel Gear

2402ZHS01-356

—

—

—

13

Rear Axle Driven Bevel Gear

To be Used Together with Driving Bevel Gear

2402ZH1827-026

—

—

—

14

Rear Axle Driving Bevel Gear

Wear Part, To be Used Together with Driven Bevel Gear

2402ZH1827-025

—

—

—

15

Hexagon Bolt

Q151B1475-0H1-J1

—

—

—

16

Retaining Plate Differential Bearing Cover

2402ZHS01-383

—

—

—

17

Locking Bolt

2402ZHS01-119

—

—

—

18

Supporting Washer - Half Axle Gear

2402ZHS01-336

—

—

—

19

Half Axle Gear - Bevel Gear Differential

Wear Part

2402ZHS01-335

—

—

—

20

Shim Differential Gear

2402ZHS01-346

—

—

—

21

Planetary Gear - Bevel Gear Differential

Wear Part

2402ZHS01-345

—

—

—

22

Spider Bevel Gear Differential

Wear Part

2402ZHS01-331

—

—

—

−
