2510ZHS01-410

Inter-axle Differential Assembly

2510ZHS01-410

—

Q40512

Тяжелая пружинная шайба

Q40512

—

Q151B1245-0H1

Hexagon Bolt

Q151B1245-0H1

—

2502ZHS01-084

Adjusting Washer

As Required

2502ZHS01-084

—

2502ZHS01-083

Adjusting Washer

As Required

2502ZHS01-083

—

2502ZHS01-082

Adjusting Washer

As Required

2502ZHS01-082

—

2402ZHS01-384

Retaining Plate Differential Bearing Cover

2402ZHS01-384

—

2402ZHS01-356

Bolt - Driven Bevel Gear

2402ZHS01-356

—

2402ZHS01-382

Adjusting Nut Differential Bearing

2402ZHS01-382

—

2401ZHS01-028

Locating Pin

2401ZHS01-028

—

Q40512

Тяжелая пружинная шайба

Q40512

—

Q151B1245-0H1

Hexagon Bolt

Q151B1245-0H1

—

24N-01066

Уплотнительная шайба

24N-01066

—

24N-01066

Уплотнительная шайба

24N-01066

—

2502010-T1700

Middle Axle Main Retarder and Bevel Gear Differential Assembly

2502010-T1700

—

2510ZHS01-055

Oil Seal and Oil Seal Seat Assembly - Middle Axle Input End

2510ZHS01-055

—

1

Nut

2402ZHS01-072

—

2

Washer

2402ZHS01-071

—

3

Flange Assembly - Middle Axle Input End

2502ZHS01-065

—

4

O Ring - Flange

2502ZHS01-038

—

5

Oil Seal Assembly - Middle Axle Input End

2510ZHS01-056

—

6

Oil Seal Seat - Straight-through Shaft Input End

2510ZHS01-057

—

7

Deep Groove Ball Bearing

Wear Part

6315

—

8

Пробка сливного отверстия в сборе

24N-01072

—

9

Пробка отверстия уровня масла

24N-01065

—

10

Inter-axle Differential Case

2510ZHS01-411

—

11

Bush

2510ZHS01-426

—

12

Rear Gear and Bush Assembly

2510ZHS01-435

—

13

Backing Ring - Differential Gear

2510ZHS01-446

—

14

Planetary Gear Inter-axle Differential

Wear Part

2510ZHS01-445

—

15

Spider - Inter-axle Differential Assembly

Wear Part

2510ZHS01-431

—

16

Rear Side Gear

2510ZHS01-437

—

17

Wearing Shim

2510ZHS01-438

—

18

Half Axle Gear - Bevel Gear Differential

Wear Part

2402ZHS01-335

—

19

Connecting Sleeve

2510ZHS01-422

—

20

Cylindrical Gear Cover

2502ZHS01-102

—

21

Bearing Inner Race Assembly

Wear Part, To be Used Together with Inner Race

30222-2

—

22

Bearing Outer Race

Wear Part, To be Used Together with Outer Race

30222-1

—

23

Driving Cylindrical Gear Assembly

To be Used in Pair with Driven Cylindrical Gear

2510ZHS01-450

—

24

Locating Sleeve

24ZHS01-05067

—

25

Driven Cylindrical Gear - Straight-through Axle

To be Used in Pair with Driving Cylindrical Gear

2502ZHS01-051

—

26

Shim Differential Gear

2402ZHS01-346

—

27

Tapered Roller Bearing

Wear Part

32315

—

28

Deep Groove Ball Bearing

Wear Part

6216

—

29

Middle Axle Driving Bevel Gear

Wear Part, To be Used in Pair with Driven Bevel Gear

2502ZH1827-025

—

30

Bevel Bearing - Driving Bevel Gear

27314E

—

31

Planetary Gear - Bevel Gear Differential

Wear Part

2402ZHS01-345

—

32

Spider Bevel Gear Differential

Wear Part

2402ZHS01-331

—

33

Differential Lock Control Cylinder

25ZHS01-11023

—

34

O Ring

25ZHS01-11017

—

35

Differential Lock Piston

25ZHS01-11016

—

36

Spring

25ZHS01-11022

—

37

Sensor Assembly

25ZHS01-11021

—

38

Differential Lock Cylinder Cap

25ZHS01-11011

—

39

Shifting Fork Shaft

25ZHS01-11015

—

40

Shifting Fork - Shaft Differential

25ZHS01-11026

—

41

Adjusting Nut - Differential Bearing

2402ZHS01-381

—

42

Bearing Outer Race

Wear Part, To be Used Together with Inner Race

32216-1

—

43

Bearing Inner Race Assembly

Wear Part, To be Used Together with Outer Race

32216-2

—

44

Middle Axle Driven Bevel Gear

Wear Part, To be Used in Pair with Driven Bevel Gear, 2502ZH1827-025 and 2502ZH1827-026 should be replaced in pair

2502ZH1827-026

—

45

Locking Bolt

2402ZHS01-119

—

46

Retaining Plate Differential Bearing Cover

2402ZHS01-383

—

47

Supporting Washer - Half Axle Gear

2402ZHS01-336

—

48

Adjusting Washer

As Required

2502ZHS01-081

—

Каталог запасных частей к технике: DongFeng L3251A3 (вар.). Middle Axle Main Retarder
