11030100

Middle lower guard board sub-assembly, the passenger side instrumental panel

Include 31

11030100

—

RQ2700512A

Винт

RQ2700512A

—

10116700

Spring clip

10116700

—

RQ2790616

Винт

RQ2790616

—

10116700

Spring clip

10116700

—

RQ2790616

Винт

RQ2790616

—

10116600

Spring clip

10116600

—

10116700

Spring clip

10116700

—

10934100

Right instrument cover assembly

Include 12

10934100

—

10116700

Spring clip

10116700

—

11030000

Middle lower guard board sub-assembly, the driver side instrumental panel

Include 23

11030000

—

10399800

Middle instrument cover assembly

Include 11

10399800

—

10505200

Right block plate assembly,instrument panel

Include 33

10505200

—

10116700

Spring clip

10116700

—

10116600

Spring clip

10116600

—

RQ2790616

Винт

RQ2790616

—

10106400

Nut

10106400

—

10505100

Lower guard plate craft sub-assembly

Include 32

10505100

—

RQ2700625A-Z5

Винт

RQ2700625A-Z5

—

RQ2790616

Винт

RQ2790616

—

RQ2700512A

Винт

RQ2700512A

—

10504900

Left lower block plate assembly, instrument panel

Include 26

10504900

—

RQ2790616

Винт

RQ2790616

—

10116600

Spring clip

10116600

—

10116600

Spring clip

10116600

—

1

Left body, instrument panel

10397000

—

2

Nut

10106400

—

3

Damping rubber nail

10399500

—

4

Lock pin

10399600

—

5

Nut, spring piece

10116800

—

6

Гайка

Q32006

—

7

Right body, instrument panel

10397100

—

8

Винт

RQ2700625A-Z5

—

9

Left instrument cover

10504200

—

10

Spring clip

10116700

—

11

Middle instrument cover

10397300

—

12

Right instrument cover

10504300

—

13

Spring clip

10116600

—

14

Right air outlet assembly, driver side

10114400

—

15

Left air outlet assembly, driver side

10114500

—

16

Right air outlet assembly, passenger side

10114600

—

17

Left air outlet assembly, passenger side

10114700

—

18

Fuse box cover

10397500

—

19

Fuse shield

10397600

—

20

Left knee guard board

10397700

—

21

Right knee guard board

10397800

—

22

Middle lower guard board, driver side instrument panel,A

10504400

—

23

Middle lower guard board, driver side instrument panel,B

11029600

—

24

Snap

10116900

—

25

Винт

RQ2790616

—

26

Left lower block plate, instrument panel

10397900

—

27

Винт

RQ2790616-Z5

—

28

Right upper filling-up plate, instrumental panel

10398000

—

29

Винт

RQ2700516

—

30

Винт

RQ2720516

—

31

Middle lower guard board, instrument panel, passenger side

10504600

—

32

Lower guard plate, instrument panel passenger side

10398200

—

33

Right block plate,instrument panel

10398300

—

34

Винт

RQ2700512A

—

Каталог запасных частей к технике: DongFeng DFL-3251AW1. Instrument Panel Group
