Каталог запасных частей к технике: XINCHAI 4D32ZT31. Engine block assembly and accessory

Cylinder head and gas exchanging system assembly →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Pin 16h8x20

GB/T119.1-16h8x20

—

Cylinder head gasket

A498B-01004

—

Engine block

A498BZ-01001

—

Plug

490B-01029

—

Plug screw NPT1/4

490B-01081-1

—

Plug

490B-01080

—

Bowl-shaped plug 60

495B-01050

—

Rear camshaft bush

495B-01008A

—

Bowl-shaped plug 58

490B-01009

—

Upper crankshaft thrust plate

495B-01026A

—

Lower crankshaft thrust plate

495B-01022A

—

Middle blocking

490B-01027

—

Upper main bearing shell

495B-01034A

—

Lower main bearing shell

495B-01033A

—

Rear main bearing cover

A498B-01023

—

Main bearing cover

A498B-01032

—

Main bearing bolt

А498В-01019А

—

Bowl-shaped plug 50

495В-01047

—

Camshaft bush

495В-01007А

—

Pin 8x20-B

GB/T119.2-8x20-B

—

Water inlet cover

A498BZL-01082-1

—

Washer 8

GB93-8 I

—

Воlt M8х16

GB/T5783-M8x16

—

Plug

490B-01079

—

Cylinder liner

A498B-01005

—

Drain valve unit

490BT-01100

—

Hose clamp d16

JB/T8870-d16

—

Drain valve hose

490BT-01075

—

Drain valve hose bracket

490BT-01105

—

−
