Каталог запасных частей к технике: Great Wall GW-491QE. Cylinder block assembly (1)

← Cylinder head assembly (2) Cylinder block assembly (2) →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Clutch box right bracket

1002023-E00

—

Clutch box left bracket

1002024-E00

—

Locating pin

B8x18

GB/T119.1-2000

—

Locating pin

B10x22

GB/T119.1-2000

—

Water drain switch set

1305010-E00

—

Lower main bearing shell

5/SET

1002017-E07

—

Higher main bearing shell

5/SET

1002018-E07

—

Higher thrust plate

1002019-E00

—

Lower thrust plate

1002021-E00

—

Tail oil duct plug

1002047-E00

—

Main oil duct plug

1002048-E00

—

Cylinder block

1002031-E07

—

Cam shaft bearing I

1002042-E00

—

Cam shaft bearing II

1002043-E00

—

Cam shaft bearing III

1002044-E00

—

Cam shaft bearing IV

1002045-E00

—

Cam shaft bearing V

1002046-E00

—

Main bearing cap bolt

1002037-E00

—

Main bearing cap

1002034-E00

—

Middle main bearing cap

1002035-E00

—

Cylinder head locating pin sleeve

1002041-E00

—

−

40%
