Каталог запасных частей к технике: FAW BF4M2012. CRANKCASE AND CONNECTION HOUSING

Каталог запасных частей к технике: FAW BF4M2012. CRANKCASE AND CONNECTION HOUSING

← ENGINE SUPPORT BRACKET CYLINDER HEAD →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

JA1002-52D-4

Safety/lock.agentн

SAFETY/LOCK.AGENTН 699 -DEUTZ DW 67-2000 ML

JA1002-52D-4

—

—

—

1

Bearing bush

1006028-56D

—

—

—

1

Bearing bush

04250086

—

—

—

2

Bearing bush

1006024-56D

—

—

—

2

Bearing bush

04251884

—

—

—

3

Crankcase

1002014-65D

—

—

—

4

Core hole plug

CORE HOLE PLUG H2860-A36-ST -FE/ZNPHR

1002620-52D

—

—

—

5

Core hole plug

CORE HOLE PLUG H2860-A45-ST -FE/ZNPHR

1002623-52D

—

—

—

6

Core hole plug

CORE HOLE PLUG H2860-A36-ST -FE/ZNPHR

1002620-52D

—

—

—

7

Screw plug

SCREW PLUG H2812-906 -M30X1,5-ST-A4C-PRE80

01180890

—

—

—

8

Screw plug

SCREW PLUG H2812-906 -M22X1,5-ST-A4C-PRE80

01180906

—

—

—

9

Screw plug

SCREW PLUG H 2812-906 -M14X1,5-ST-A3C-L0CTITE 5061

01182031

—

—

—

10

Screw plug

SCREW PLUG DIN 908 -M14X1,5-ST-ZNPHRF

1002626-52D

—

—

—

11

Screw plug

SCREW PLUG DIN 7604-AM14X1,5-ST-A4C

1002622-52D

—

—

—

12

Уплотнительная прокладка

SEALING RING DIN 7603-A14X20-CU

1104617-52D

—

—

—

13

Ball

BALL GB308 6G20

1002621-52D

—

—

—

14

Safety/lock.agent

SAFETY/LOCK.AGENT H 699 -DEUTZ DW 72-250 ML

JA1002-52D-3

—

—

—

15

Screw plug

04226536

—

—

—

16

Ball

BALL GB308 8G20

1307649-52D

—

—

—

17

Rivet

RIVET H 2416-С3,8X 5-AL

01174823

—

—

—

18

Name plate

1002201B52D

—

—

—

19

Piston cool. Nozzle

1004076-52D

—

—

—

19

Piston cool. Nozzle

04207521

—

—

—

20

Connection housing

1002061-84D

—

—

—

21

Bush

1002064-52D

—

—

—

22

Stud

CQ1201032TF36S

—

—

—

23

Torx-head bolt

H2032-HBM12X150-10.9 -ZNAL-A

1002667-56D

—

—

—

24

Torx-head bolt

H2032-HBM16X140-10.9-ZNAL-A

1002668-56D

—

—

—

25

Torx-head bolt

H2032-HBM12X80-10.9- GESCHW

1002669-56D

—

—

—

26

Torx-head bolt

H2032-HBM16X75-10.9- GESCHW

1002672-56D

—

—

—

27

Cover plate

1002063-52D

—

—

—

28

Hexagon bolt washer assembly

CQ1460616TF36

—

—

—

29

Hexagon bolt washer assembly

CQ1460612TF36

—

—

—

30

Cover plate

1002071-56D

—

—

—

31

Gear housing and lip seal

1002050-56D

—

—

—

32

Rot.shaft lip seal

1005105B56D

—

—

—

32

Rot.shaft lip seal

04253332

—

—

—

33

Болт с шестигранной головкой и фланцем

EN 1662-F-M8X35-10.9-ZNAL-A

1009626-52D

—

—

—

35

Hexagon bolt

HEXAGON BOLT EN 1662 -F-M 8 X 45- 10.9-ZNAL-A

1002614-56D

—

—

—

38

Set screw

SET SCREW GB77-M6X10-45H DIN 913-M6X10-45H

1002653-52D

—

—

—

39

Safety/lock.agent

SAFETY/LOCK.AGENT H 699-DEUTZ DW 72- 50 ML

JA1002-52D-2

—

—

—

40

Thrust main bearing cap

1002022-56D

—

—

—

41

Bush

1002024-56D

—

—

—

42

Hexagon bolt

1002023-56D

—

—

—

43

Main bearing cap

1002021-56D

—

—

—

44

Bypass pipe assembly

1005295-65D

—

—

—

44

Bypass pipe assembly

04291215

—

—

—

45

Bypass pipe joint

04255998

—

—

—

45

Bypass pipe joint

1005294-65D

—

—

—

46

Ball

GB308 8G20

1307649-52D

—

—

—

47

Mass balanc. Shaft gear

1005231-65D

—

—

—

48

Mass balanc. Shaft

WITH GEAR

04298246

—

—

—

48

Mass balanc. Shaft

WITH GEAR

1005220-65D

—

—

—

48

Mass balanc. Shaft

04298244

—

—

—

48

Mass balanc. Shaft

1005221-65D

—

—

—

49

Bush

04252834

—

—

—

49

Bush

1005226-65D

—

—

—

50

Thrust washer

04251810

—

—

—

50

Thrust washer

1005234-65D

—

—

—

51

Hexagon bolt

H 2091- 4017-M 8 X 16- 10.9-GESCH W-MK-1

1005627-65D

—

—

—

52

Hexagon screw

H 2091- 7991-M 8 X 45- 10.9-GESCH W-MK-1

1005658-65D

—

—

—

53

Fastening ring

1005263-65D

—

—

—

53

Fastening ring

4255410

—

—

—

54

Journal

04288828

—

—

—

54

Journal

1005251-65D

—

—

—

55

Toothed gear

1005256-65D

—

—

—

55

Toothed gear

04255906

—

—

—

55

Toothed gear

WITH BUSH

0425590)

—

—

—

55

Toothed gear

WITH BUSH

1005255-65D

—

—

—

56

Bush

1006047-52D

—

—

—

56

Bush

04197518

—

—

—

57

Fastening ring

WITH FEED LINE

1005260-65D

—

—

—

57

Plain washer

1005264-65D

—

—

—

58

Lubricant feed line

1005265-65D

—

—

—

59

O-ring

H 2927- 7 X 1,5 -ACM-1-70

1005668-65D

—

—

—

59

O-ring

H 2927- 7 X 1,5 -ACM-1-70

01181582

—

—

—

−
