Каталог запасных частей к технике: Deutz LKSR. Crankshaft

← Front wall cover Crankshaft →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Flywheel with gear ring

for Manet-Generator : 99901.071.009.4, (with fig. No. 1, 2)

99871.145.115.5

—

Flywheel

for Manet-Generator : 99901.071.009.4

99871.145.015.4

—

Gear wheel

99871.375.003.4

—

Dowel

8x18 DIN 1472

60220.20.0.8018

—

Bearing bracket

for Manet-Generator : 99901.071.009.4

99871.420.003.5

—

Bearing bracket

for Manet-Generator : 99871.071.015.4 (with fig. No. 24)

99871.420.005.5

—

Bearing bracket

for Manet-Generator : 99901.071.009.4

99871.420.003.4

—

Bearing bracket

for Manet-Generator : 99871.071.015.4

99871.420.005.4

—

Gasket

101.069.00.00

—

Roller bearing

NJ2012/C2 NA DIN 5412

91322.24.6.2012

—

Counter-weight

69870.670.001.4

—

Spring washer

A10 DIN 137

60216.03.0.0100

—

Cheese head screw

M10x45 DIN 912-10.9

60200.70.0.1045

—

Bearing bush

69870.432.001.4

—

Clampнng sleevee

4x16 DIN 1481

60220.15.0.0416

—

Bearing ring

69870.433.002.4

—

Front gear wheel

101.061.05.00

—

Support with governor weig

99871.620.001.5

—

Lock washer

B6 DIN 127

60216.01.0.0060

—

−
