Каталог запасных частей к технике: King Long XMQ-6135. 34-0484 Steering system (II)

← 34-0172 Steering system (I) 35-1305 Braking system →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Steering oil tank, 2, transparent (integrated oil pan)

Contains 2

234600016

—

Filter element, oil tank, power-steering

234000060

—

Hose ring band

567503500

—

Rubber sheet,D55,D40,D32

452040082

—

Rubber sheet,D55,D40,D23

452040083

—

Steering oil return pipe assembly, inner diameter d13, l=4600mm

361100053

—

Oil-resistant rubber tube, 22,700x100

361100060

—

Steering oil inlet pipe assembly,D22,1.5

370700810

—

Steering pump assembly, WP10

234500178

—

Card sleeve combination right angle connector body-D14, M20x1.5

581514000

—

Nuts for sleeve type pipe joints-D14, M20x1.5

580114000

—

Card holder-D14

580014000

—

Straight connector, M20, M18

350200480

—

Sealing gasket-d18

572318000

—

Sealing gasket-D27

572327000

—

Straight connector, M26, d22

350201030

—

Steel pipe,d14x1.5,20#

413272120

—

Polyurethane reinforced steering pressure hose, zw2450

361100140

—

−

40%
