Каталог запасных частей к технике: King Long XMQ-6135. 15-0192 Fan clutch

← 15-0191 Pulley adapter 16-0205 Clutch operating mechanism →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

213700065

Fan clutch assembly, 168, double b slot, double flexibility, high torque

213700065

—

Pulley, 168, double b groove, 2137000065 (after 2020.04)

The old state before 2020.04 used 213000772

213000771

—

Mandrel,213700055(202004-)

The old status before 2020.04 used 213000638

213000697

—

Imported double row angular contact ball bearing, 3208b-2rs, 213700064

213000639

—

Inner spacer, 213700064(202004-)

The old status before 2020.04 used 213000640

213000715

—

Outer spacer, 213700064(202004-)

The old status before 2020.04 used 213000641

213000714

—

Spacer sleeve,213700064

213000642

—

Fixed bracket assembly, 2137000065

213000773

—

Electromagnetic lower body flange assembly, 213700055 (202004-)

The old state before 2020.04 used 213000698

213000745

—

Magnetic induction disk,213700055

213000699

—

Radiator assembly,213700055(202004-)

The old state before 2020.04 used 213000742

213000701

—

10.1

Imported deep groove ball bearing, 6206-2rs, 213700058

Included in radiator assembly section

213000665

—

10.2

Imported double row angular contact ball bearing, 3206b-2rs, 213700055

Included in radiator assembly section

213000700

—

10.3

Radiator connection mandrel, 213700055(202004-)

The old state before 2020.04 used 213000743

213000744

—

Thick washer m16x37x8,213700064

213000647

—

Connecting bolt,213700064(202004-)

The old state before 2020.04 used 213000648

213000716

—

Bolt,m8x22,q150b0822

217001436

—

Bolt-m6, l15, grade 8.8, galvanized passivated, hexagonal head

515006150

—

Spring washer

540306000

—

Nut-m6, grade 8, galvanized passivated, type 1 hex

534006000

—

−
