235800319

Retarder assembly-mechanical part, TB24B, 511171101

235800319

—

235000113

Screw, hexagon head cap

235000113

—

235000037

Spring washer

235000037

—

235000109

Screw, hexagon head cap

235000109

—

235000108

Support block

235000108

—

235000024

Damping rubber cushion

235000024

—

218000300

Auxiliary bracket dummy part,TB17,539378175

218000300

—

235001239

Wiring cover (4 wiring holes), TB15, 235801200 (post-2015 status)

235001239

—

235001238

Terminal block (4 terminals), TB15, 235801200 (post-2015 status)

235001238

—

235001237

Junction box assembly (4 terminals), TB15, 235801200 (post-2015 status)

235001237

—

235001960

Rotor assembly,TB24B,511171101

235001960

—

235000103

Rotor shims

235000103

—

235001833

Stator adjustment gasket

235001833

—

235001832

Stator adjustment gasket

235001832

—

1

Spring washer

235000087

—

2

Drive shaft nut, M14x1.5, grade 10

235001258

—

3

Stud,M14x1.5x70,10.9

235001825

—

4

Bolt-connected mounting plate

—

5

Hexagon nut

235000098

—

6

Spring washer

235000100

—

7

Hexagon nut

235000099

—

8

Spring washer

235000037

—

9

Turntable

235000102

—

10

Stator assembly

235001958

—

11

Hexagon head bolt M12Ч60

235001829

—

12

Hexagon head bolt M12Ч60

235001829

—

13

Spring washer

235000037

—

14

Nut

235000079

—

15

Spring washer

235000036

—

16

Connecting ring

235000761

—

17

Turntable

235000101

—

18

Fixed bracket

235001959

—

19

Special flange

—

20

Stator adjustment gasket

235001831

—

21

Hexagon head bolt M12Ч60

235001829

—

22

Spacer

235001834

—

23

Heat shield-retarder, Kaimai DHB17

313300261

—

Каталог запасных частей к технике: King Long XMQ-6127. Retarder 235800319
