Каталог запасных частей к технике: King Long XMQ-6127. Clutch and transmission housing assembly

← Two axis Front air suspension 229400294 →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Clutch release fork shaft

217010983

—

Spherical bearing

217006693

—

Elastic retaining ring for hole

299022625

—

Dust cover

217009596

—

Shift fork bushing

217010986

—

Retaining rings for shafts

299012483

—

Clutch release fork

217010985

—

Separate shift fork bracket

217010984

—

Hex head bolt and spring washer assembly

1421235

—

Clutch release bearing assembly

217010982

—

Pre-glued hex head bolt and spring washer assembly

217009876

—

Pre-glued hex head bolt and spring washer assembly

217009294

—

One shaft bearing cap gasket

217006670

—

Type 1 non-metallic insert hexagonal lock nut

217009249

—

Flat Washers

217009250

—

Stud bolt

217006666

—

Clutch housing

217010980

—

Clutch housing gasket

217006685

—

Gearbox housing

217006668

—

Studs

217009854

—

Heavy-duty spring washer

540316000

—

Type 1 hexagonal nut

534116000

—

O-ring

217006687

—

Oil clog

217006688

—

Oil plug and magnet sub-assembly

217009853

—

Clutch hand hole cover

217006710

—

Hex head bolt and spring washer assembly

Q1420812

—

One shaft bearing cap

217006669

—

Pre-glued hex head bolt and spring washer assembly

217009241

—

−

40%

Clutch and transmission housing assembly
