Каталог запасных частей к технике: King Long XMQ-6127. Assembly, water pump

← Assembly, warm air&water intake valve Clutch parts →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Screw plug

NPT 1/4

Q618B02

—

Cover, thermostat

L3002-1306001

—

Gasket, thermostat

L3000-1306013

—

Thermostat

530-1306010

—

Screw plug

NPT 1/2

Q618B04

—

Screw plug

177-1306023

—

Bolt

M14x1.5x18

Q151B1418

—

Ribbed belt

8PK1490

L3002-1307042

—

Belt pulley, water pump

L3000-1307011

—

Retaining ring 52

Q43052

—

Bolt

M10x85

Q1841085TF2

—

Assembly, warm air & water intake valve

6105Q-1305100

—

Water pump

L33QA-1307000

—

Bearing, connected to shaft

L3000-1307012

—

Assembly, waterseal

C6A/F-5/8

L3000-1307013

—

Impeller

L3000-1307026

—

Gasket, water pump

L3000-1307017A

—

Cover plate, water pump

L3000-1307018A

—

Bolt

M8x22

Q150B0822

—

O-sealing ring

40x3.55

GB3452.1-35504000

—

O-sealing ring

35.5x3.55

GB3452.1-35503550

—

Connection pipe

L3000-1307016

—

Gasket 8

Q40108

—

Gasket 8

Q40308

—

Bolt

M8x35

Q150B0835

—

−
