Каталог запасных частей к технике: King Long XMQ-6127. Assembly, crankshaft&flywheel

← Assembly, piston & connecting rod Assembly, camshaft →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Bolt, belt pulley

A3100-1005034A

—

Belt pulley

A3100-1005032D

—

Cylindrical pin

A8x14

Q5210814

—

Damper, silicon oil

L3000-1005030B

—

Gasket 10

Q40310

—

Socket head cylindrical screw

M10x25

Q218B1025TF2

—

Crankshaft timing gear

A3100-1005021B

—

Cotter pin

A3100-1005018

—

Crankshaft

L3000-1005019A

—

Thrust shoe, crankshaft

top

L3000-1005012A

—

Main bearing bush

top

L3000-1005014

—

Gasket, bearing

E0248-1005065

—

Ball bearing, deep groove

6205-Z

GB/T276

—

Gear ring, flywheel

L3000-1005040

—

Flywheel

L3000-1005041A

—

Bolt, flywheel

6QA1-1005044A

—

Dowel pin

6105Q-1005042

—

Main bearing bush

bottom

L3000-1005016

—

Thrust shoe, crankshaft

bottom

L3000-1005013A

—

−
