224004953

Inclined thrust rod seat

Installed above the rear cover of the axle housing

224004953

—

224001587

Rear right spring energy storage brake chamber assembly

224001587

—

224001549

Right disc brake assembly

224001549

—

224006618

Hexagon head bolts

Installed above the rear cover of the axle housing

224006618

—

540516000

Spring washer

Installed above the rear cover of the axle housing

540516000

—

1

Rear axle housing assembly

224005414

—

2

Breather plug assembly

224004836

—

3

Drain plug

224002242

—

4

Sealing washer

224001221

—

5

Plug

224001220

—

6

Rear axle main reducer assembly

224004954

—

7

Heavy duty spring washers

Fasten the main reducer to the axle housing assembly.

540514000

—

8

Hexagon head bolts

Fasten the main reducer to the axle housing assembly.

224002157

—

9

Stud bolts-for fastening the reducer

Fasten the main reduction to the axle housing assembly and install it in the up and down direction.

224001219

—

10

Heavy duty spring washers

Fasten the main reduction to the axle housing assembly and install it in the up and down direction.

540514000

—

11

Type 1 hexagonal nut

Fasten the main reduction to the axle housing assembly and install it in the up and down direction.

534114000

—

12

Sensor

230003274

—

13

Sensor bush

224001746

—

14

Sensor holder

224005410

—

15

Hexagon head bolts

Fasten the ABS sensor bracket to the side of the axle housing bearing

515006350

—

16

Spring washer

Fasten the ABS sensor bracket to the side of the axle housing bearing

540306000

—

17

Bolt

515008120

—

18

Spring washer

540308000

—

19

Clip - secures sensor wires

230001580

—

20

Bolt

Fasten disc brake to axle housing flange

224002180

—

21

Spring washer

Fasten disc brake to axle housing flange

540520000

—

22

Brake chamber

224001586

—

23

Left disc brake assembly

224001548

—

24

Rear hub and brake disc with stud bolt assembly

224007622

—

25

Lock Washer-Wheel Bearing Nut

224005245

—

26

Rear hub adjustment nut

224005246

—

27

Pad-Axle Shaft

224005244

—

28

Rear axle half shaft

224005243

—

29

Taper sleeve

224005374

—

30

Half shaft nut

224005373

—

31

Wheel nuts

224004079

—

Каталог запасных частей к технике: King Long XMQ-6106. Assembly of bridge assembly components
