Каталог запасных частей к технике: Higer KLQ6826Q. REAR BRAKE ASSY

← FINAL DRIVE AND BEVEL GEAR DIFFERENTIAL ASSY TYRE AND RIM →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

35A16-02600

Rear brake plate with brake shoe assembly

35A16-02600

—

Brake shoe, lining and roller assy

35A11-02610

—

Lower dust cover

35A23-02539

—

Upper dust cover

35A23-02540

—

Block

35K67-02503

—

35A46-02508

—

05.1

Brake chamber bracket

35A16-02605

—

05.2

Brake chamber bracket

35A16-02606

—

06.1

Brake air chamber assy

35A16-19501

—

06.2

Brake air chamber assy

35A16-19502

—

07.1

Rear left camshaft

35A16-02603

—

07.2

Right after the camshaft

35A16-02604

—

Bush

35K65-02521

—

Oil seal assy

30E03-00010-02024

—

Washer

35NA4-01510

—

11.1

Self-adjusting arm assy

35KA5-51501

—

11.2

Self-adjusting arm assy

35KA5-51502

—

Brake plate bushing

35GE1-02504

—

Grease nozzle

22J3C-01539

—

After the brake plate and sleeve assembly

35A23-02538

—

Oil seal assy

30E03-00010-02024

—

Roller shaft

35A23-02543

—

Roller assembly

35A23-02544

—

Rivet

35G13-02555

—

Brake friction lining

(400-180)

35A23-02545

—

Return spring

35G13-02560

—

Rear brake shoe

35A11-02601

—

Shaft, brake shoe

35G13-02514

—

Bush-brake shoe

35G13-02511

—

−
