Каталог запасных частей к технике: Higer KLQ6129. FRONT SUSPENSION SYSTEM

Каталог запасных частей к технике: Higer KLQ6129. FRONT SUSPENSION SYSTEM

← SPARE WHEEL BRACKET REAR SPRING PARTS →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

29W02-30100

Air suspension

Steering axle air suspension (imported)

29W02-30100

—

—

—

1

Fixing chassis frame bracket

Frame bracket (fixed)

29W02-30100x02045

—

—

—

2

Adjustable chassis frame bracket

Frame bracket (adjustable)

29W02-30100x02046

—

—

—

3

Leaf spring

Leaf spring (component)

29E01-30100x02040

—

—

—

3.1

Rubber bushing

Rubber bushing

29E01-30100x02043

—

—

—

4

Protection clamping plate

Protective splint

29W02-30100x02044

—

—

—

5

Fixing backplate, left

Positioning pad (left)

29W02-30100x02025

—

—

—

6

Fixing backplate, right

Positioning pad (right)

29W02-30100x02056

—

—

—

7

Air spring lower plate

Mounting plate under air spring

29E01-30100x02023

—

—

—

8

Shock absorber upper bracket

Shock absorber upper bracket

29W02-30100x02031

—

—

—

9

Lower bracket

Shock absorber lower bracket

29W02-30100x02032

—

—

—

10

Shock absorber

Shock absorber

29E01-30100x02030

—

—

—

11

Left bracket, torsion bar

Torsion bar left bracket

29W02-30100x02011

—

—

—

12

Torsion bar

Torsion bar (component)

29V55-03540

—

—

—

12.1

Torsion bar left end

Torsion bar left end (left thread)

29V55-03541

—

—

—

12.2

Torsion bar end, right

Right end of torsion bar

29V55-03542

—

—

—

12.3

Bushing

Bushing

29V55-03543

—

—

—

13

Air spring

Air spring

29E01-30100x02020

—

—

—

14

Retaining adjusting block

Positioning adjustment block

29E01-30100x02041

—

—

—

15

Lower bracket, rear height valve

29A23-43002

—

—

—

16

Air spring upper plate

29W02-30100x02022

—

—

—

17

Gusset plate

29W02-30100x02021

—

—

—

18

Torsion bar bracket, right

29W02-30100x02012

—

—

—

19

Stabilizer bar assembly

29W02-30100x02050

—

—

—

19.1

Bushing

29E01-30100x02012

—

—

—

20

Connection rod

Connecting rod (component)

29W02-30100x02053

—

—

—

20.1

Bushing

Bushing

29E01-30100x02012

—

—

—

21

Connection rod plate

Connecting rod plate

29W02-30100x02051

—

—

—

22

Clip

Clamp

29W02-30100x02054

—

—

—

23

Bushing

Bushing

29W02-30100x02055

—

—

—

24

Axis pin gasket

Pin gasket

29E01-30100x02042

—

—

—

25

Dowel pin

Positioning pin

29E01-30100x02024

—

—

—

26

Hex bolt

Hexagon bolt 1”-8X6.5”

29W02-03502

—

—

—

27

Lock nut

Self-locking nut 1”-8B grade

29W02-03503

—

—

—

28

Hex bolt

Hexagonal bolt 0.75"-10X4”75" grade 8

29W02-03504

—

—

—

29

Lock nut

Self-locking nut 0.75"-10C grade

29W02-03505

—

—

—

31

Hex bolt

Hexagonal bolt 0.75"-10X4”25" grade 8

29W02-03507

—

—

—

35

Hex bolt

Hexagonal bolt 0.75"-10X5”5" grade 8

29W02-03512

—

—

—

36

Hex bolt

Hexagonal bolt 0.75"-10X3”5" grade 8

29W02-03513

—

—

—

37

Hex bolt

Hexagonal bolt 0.625"-11X2”75" Grade 5

29W02-03514

—

—

—

38

Plain washer

Flat washer 0.65”

29W02-03515

—

—

—

39

Hex nut

Hexagon nut 0.625"-11B grade

29W02-03516

—

—

—

40

Lock nut

Self-locking nut 0.75”-10B grade

29W02-03517

—

—

—

41

Hex bolt

Hexagonal bolt 0.75"-10X3”25" grade 8

29W02-03518

—

—

—

42

Hex bolt

Hexagonal bolt 0.75"-10X2”5" grade 8

29W02-03519

—

—

—

43

Hex bolt

Hexagonal bolt 0.625"-11X3”25" Grade 8

29W02-03521

—

—

—

44

Hex nut

Hexagon nut 0.625"-11C grade

29W02-03522

—

—

—

45

Hex bolt

Hexagonal bolt 0.625"-11X2" Grade 8

29W02-03523

—

—

—

46

Height control valve

Height valve (for four airbags)

29E01-43100x01020

—

—

—

46.1

Accessories

Height valve accessories (for four airbags)

29VSZ-43520

—

—

—

47

Height valve connection rod

Height valve connecting rod (for four airbags)

29E01-43100x01021

—

—

—

46

Height control valve

Height valve (for six airbags)

29V47-43010

—

—

—

46.1

Accessories

Height valve accessories (for six airbags)

29V47-43501

—

—

—

47

Height valve connection rod

Height valve connecting rod (for six airbags)

29V47-43502

—

—

—

−
