Каталог запасных частей к технике: Golden Dragon XML6845CN-3150236. STEERING OPERATION BOOSTING PIPELINE

← STEERING SYSTEM TRANSMISSION OPERATING MECHANISM →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Mounting bracket, steering oil tank

6105E05-3408110

—

Bolt

Not retail

Q150B1040

—

Plane washer

Not retail

Q40110

—

Spring washer

Not retail

Q40310

—

Nut

Not retail

Q340B10

—

Clamp, power steering oil tank

6155E01-3406011

—

Oil can assembly, steering assistant

7636472523

—

Oil tube

FYNYJG22X5

—

Adjustable elbow connector

ZTJT-M20-16A

—

Clamp

Q67522

—

Clamp

10-16

Q67516

—

Sealing washer

not retail

JB982-20

—

Straight thread connector

not retail

GB3752.2-G14

—

Straight thread elbow connector

not retail

GB3752.1-G14

—

High-pressure oil pipeline assy, power steering

ZXGY13-14-8700

—

Transition connector

XML3425302J3F0

—

Low-pressure oil pipeline assy, power steering

ZXDY13-14-9000

—

Hose clamp

not retail, 40

8111-009A0

—

Transition connector, drain valve

6125G11-3406211

—

Drain valve

Y1-910-07-00-010

—

Transition connector, drain valve

6155E01-3406502

—

−
