Каталог запасных частей к технике: Golden Dragon XML6127CNG-3141495. STEERING OPERATION BOOSTING PIPELINE

← STEERING SYSTEM 11R105-3425120 STEERING OIL CAN →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Power steering boosting can

11R105-3425120

—

Mounting plate, steering boosting

6127A28-3408027

—

Bolt

Not retail

Q150B1040

—

Plane washer

Not retail

Q40110

—

Spring washer

Not retail

Q40310

—

Nut

Not retail

Q340B10

—

Straight thread elbow connector

GB3752.1-G14

—

Oil return pipe assy, power steering

ZXDY13-14-12500

—

Sealing washer

JB982-20

—

Hose clip

8111-008A0

—

Hose clamp

Not retail, 40

8111-009A0

—

Combination bolt

Not retail

Q1460620

—

Sealing washer

JB982-20

—

Connector

GB3733.1-G14

—

High-pressure oil pipeline assy, power steering

6127A02-3406010

—

Clamp

Q67522

—

Oil tube

FYNYJG22X5

—

Sealing washer

JB982-18

—

Connecter, reservoir in

27A08-3406201

—

Clip

GB3764-18

—

Nut

G18

GB3759-G18

—

−

40%
