Каталог запасных частей к технике: Golden Dragon XML6127CNG-3141495. FRONT AXLE SYSTEM

← FRONT AXLE ASSEMBLY WHEEL HUB WITH BRAKE DISC ASSEMBLY →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Wheel hub cover, front

31N-03061

—

Paper washer

31N-03062

—

Hexagonal slotted flat nut

30N-01061

—

Wear plate

30N-01058

—

Wheel hub plate,front.left/right

3501065-ZQ50A

—

Oil seal retainer assy, front

31Z01-03075

—

Stud bolt

3001048-K2000

—

Steering knuckle assy.left/right

3001015/01016-ZQ50A

—

Left upper knuckle arm

3001044-ZQ50A

—

Steering limit screw

30N-01032

—

Wedge pin

30J-01031

—

Brake assy, left/right

3502010/3502015-ZQ99A

—

ABS sensor

35Z02-00030

—

Front axle

3001011-ZQ08P

—

Tie rod assy.

3303050-ZQ13F

—

Thrust bearing assembly

30Z01-01035

—

Steering knuckle arm, left

30Z01-01041/01042

—

Upper cover,steering knuckle

3001081-ZQ50AA

—

Paper washer

3001083-ZQ50AA

—

Adjusting washer

30Z01-01022-29

—

Main pin

30Z01-01021-A

—

Air brake chamber, front left/right

3519010/015-ZQ50A

—

−

40%
