Каталог запасных частей к технике: Golden Dragon XML6125CN-3150244. STEERING OPERATION BOOSTING PIPELINE

← STEERING SYSTEM SCHEMATIC DIAGRAM, BRAKE →

№ п/п

Название по каталогу

Кат. номер

Наименование на сайте

Ост.

Цена, BYN

Clamp, power steering oil tank

6155E01-3406011

—

Oil can assembly, steering assistant

7636472523

—

Clamp

Not retail

Q67522

—

Oil tube

FYNYJG22X5

—

Adjustable elbow connector

ZJKT-18-22

—

Sealing washer

M27

JB982-27

—

Sealing washer

Not retail

JB982-16

—

Straight thread connector

M16x1.5-G14, Not retail

XML3425301N9F0

—

Straight thread elbow connector

Not retail

GB3752.1-G14

—

High pressure oil pipeline, power steering

ZXGY13-14-12500

—

Transition connector, drain valve

6155E01-3406502

—

Drain valve

Y1-910-07-00-010

—

Transition connector, drain valve

6125G11-3406211

—

Low pressure oil pipeline, power steering

ZXDY13-14-13000

—

Adjustable elbow connector

ZTJT-M20-16A

—

Hose, oil-resist, pressure resist

14x4, Not retail

FYNYJG16X5

—

Connector

M27x1.5-G18

XML3425201K4F0

—

Connector

Q81714

—

Bolt

Q81818

—

Washer

JB1002-18

—

Bracket

6125Y27-3406012-FK36

—

−
