24ZDS01A-080

Pipe joint

24ZDS01A-080

—

1

Spring brake chamber assy

3530010-ZD01K

—

2

Spring brake chamber assy

3530010-ZD01K

—

3

Locking nut, used to fixeding brake chamber assy

832.00-3141-069

—

4

Left disc brake assy

3502010-ZD01K

—

5

Right disc brake assy

3502015-ZD01K

—

6

Locking bolt, used to fixeding disc brake assy

702.20-3141-007

—

7

Hex flange bolt, used to fixeding disc brake assy

702.01-3141-006

—

7

Hex flange bolt, used to fixeding disc brake assy

702.20-3141-006

—

8

Hex flange bolt

MVGSZ-588-M16X1.5

—

9

Axle drive shaft

BPR28-61AD-13003

—

10

Wheel nut

582.90-3140-005

—

11

Rear hub outer oil sealing seat

BPR17-43RD-40004

—

12

Rear hub outer oil sealing assy

138.31-3340-006

—

13

Rear hub outer bearing adjusting nut

BPR28-43AD-10126

—

14

Lock plate

MB-20-MSZ7890

—

15

Rear hub outer bearing adjusting nut

BPR28-43AD-10126

—

16

Lock plate

BPR17-43RD-10116

—

18

Rear hub inner oil sealing assy

BPR28-43AD-40006

—

19

Hex flange bolt, used to fixeding hub shaft tube

138.10-3310-115

—

20

Hub shaft tube

B28-51BD-10011

—

21

Bolt, used to fixeding brake plate

598.60-3300-004

—

22

Hex flange bolt, used to fixeding brake plate

BPR28-43AD-10025

—

23

Hex flange bolt, used to fixeding brake plate

BPR28-43AD-10152

—

24

Spring pin

Q5280824

—

25

Locating pin

Q5221024

—

26

Left brake plate

3502026-ZD01K

—

27

Right brake plate

3502126-ZD01K

—

28

Bolt

BPR28-46AA-10078

—

29

Screw

Q2180614

—

30

Idler pulley shaft

BPR28-46AA-10075

—

31

Adjust shim

BPR17-43RD-10181

—

31

Adjust shim

BPR17-43RD-10182

—

31

Adjust shim

BPR17-43RD-10183

—

31

Adjust shim

BPR17-43RD-10184

—

31

Adjust shim

BPR17-43RD-10185

—

31

Adjust shim

BPR17-43RD-10186

—

31

Adjust shim

BPR17-43RD-10187

—

32

Elastic ring

SB100

—

33

Double row tapered roller bearing

2402740-ZD99A

—

34

Idler pulley

BPR28-43AD-10064

—

35

Baffle block

138.10-3310-076

—

36

Compression spring

1.6X10X27-DIN2098

—

37

Thrust bearing

2402770-ZD99A

—

38

Hex flange bolt, used to fixeding half shaft

BPR28-43AD-10153

—

39

Link stopper

BPR28-43AD-10151

—

40

Left drive cylindrical gear

BPR28-43AD-10062

—

41

Right drive cylindrical gear

BPR28-43AD-10061

—

42

Left differential case retaining ring

BPR28-43AD-10045

—

43

Thrust washer

BPR28-43AD-10136

—

43

Thrust washer

BPR28-43AD-10137

—

43

Thrust washer

BPR28-43AD-10138

—

43

Thrust washer

BPR28-43AD-10139

—

43

Thrust washer

BPR28-43AD-10140

—

43

Thrust washer

BPR28-43AD-10141

—

43

Thrust washer

BPR28-43AD-10142

—

43

Thrust washer

BPR28-43AD-10143

—

43

Thrust washer

BPR28-43AD-10144

—

43

Thrust washer

BPR28-43AD-10145

—

43

Thrust washer

BPR28-43AD-10146

—

43

Thrust washer

BPR28-43AD-10147

—

43

Thrust washer

BPR28-43AD-10148

—

43

Thrust washer

BPR28-43AD-10165

—

43

Thrust washer

BPR28-43AD-10166

—

43

Thrust washer

BPR28-43AD-10167

—

43

Thrust washer

BPR28-43AD-10135

—

43

Thrust washer

BPR28-43AD-10168

—

43

Thrust washer

BPR28-43AD-10169

—

43

Thrust washer

BPR28-43AD-10170

—

43

Thrust washer

BPR28-43AD-10171

—

43

Thrust washer

BPR28-43AD-10172

—

43

Thrust washer

BPR28-43AD-10173

—

43

Thrust washer

BPR28-43AD-10174

—

43

Thrust washer

BPR28-43AD-10175

—

44

Short half shaft

I

BPR28-45CX-10043

—

45

Long half shaft

II

BPR28-45CX-10095

—

46

Snap ring

Q43745

—

47

Hexagonal bolt

Q150B0816-0H1

—

48

Lock plate

138.10-3310-055

—

49

Passive cylindrical gear dearing adjusting nut

138.10-3310-102

—

50

Tapered roller bearing

2402780-ZD99A

—

51

Passive cylindrical gear

BPR28-43AD-10085

—

52

Abs sensor gear ring

BPR28-43AD-10008

—

53

Hexagonal bolt

Q150B0816-0H1

—

53

Hexagonal bolt

Q150B0816-0H1

—

54

Lock plate

I

BPR28-43AD-10056

—

54

Lock plate

II

BPR28-43AD-10057

—

54

Lock plate

138.10-3310-055

—

55

Left differential case dearing adjusting nut

BPR28-44AB-10042

—

55

Adjusting nut-right cylindrical gear dearing

138.10-3310-092

—

56

Ring gear and differential assembly

2402310-ZD01E

—

57

Right differential case dearing adjusting nut

BPR28-43AD-10012

—

58

Adjusting nut locking bolt

BPR28-43AD-10009

—

59

Sealing cover plate

138.10-3310-005

—

60

Hexagonal bolt

Q150B0830-0H1

—

61

Hexagonal bolt

Q150B0825-0H1

—

62

Cover plate

BPR28-43AD-10053

—

63

Cross countersunk head screw

Q2140612

—

64

Left c type arm

B28-43AD-10041

—

65

Right c type arm

B28-43AD-10091

—

66

Hex flange bolt, used to fixeding c type arm

BPR28-43AD-10026

—

67

Hex flange bolt, used to fixeding c type arm

138.10-3310-018

—

68

Stud bolt, used to fixeding c type arm

138.10-3310-044

—

69

Hexagonal nut

Q341C12-0H1

—

70

Abs sensor assy

3550050-ZD01E

—

71

Screw

Q2180614

—

72

Air breather plug assy

594.00-3310-031

—

73

Axle housing

2401025-ZD01E

—

74

Oil drain plug

594.20-3310-055

—

75

Oil drain plug

594.20-3310-055

—

76

Drive pinion

M24025ZD1838

—

77

Adjust shim

BPR28-43AD-11102

—

77

Adjust shim

BPR28-43AD-11103

—

77

Adjust shim

BPR28-43AD-11104

—

77

Adjust shim

BPR28-43AD-11105

—

77

Adjust shim

BPR28-43AD-11106

—

77

Adjust shim

BPR28-43AD-11107

—

77

Adjust shim

BPR28-43AD-11108

—

77

Adjust shim

BPR28-43AD-11109

—

77

Adjust shim

BPR28-43AD-11110

—

77

Adjust shim

BPR28-43AD-11111

—

77

Adjust shim

BPR28-43AD-11112

—

77

Adjust shim

BPR28-43AD-11113

—

77

Adjust shim

BPR28-43AD-11114

—

77

Adjust shim

BPR28-43AD-11115

—

77

Adjust shim

BPR28-43AD-11116

—

77

Adjust shim

BPR28-43AD-11117

—

77

Adjust shim

BPR28-43AD-11118

—

77

Adjust shim

BPR28-43AD-11119

—

77

Adjust shim

BPR28-43AD-11120

—

77

Adjust shim

BPR28-43AD-11121

—

77

Adjust shim

BPR28-43AD-11122

—

77

Adjust shim

BPR28-43AD-11123

—

77

Adjust shim

BPR28-43AD-11124

—

77

Adjust shim

BPR28-43AD-11125

—

77

Adjust shim

BPR28-43AD-11126

—

78

Tapered roller bearing

2402720-ZD99A

—

79

Adjust spacer

BPR28-43AD-11036

—

79

Adjust spacer

BPR28-43AD-11037

—

79

Adjust spacer

BPR28-43AD-11038

—

79

Adjust spacer

BPR28-43AD-11039

—

79

Adjust spacer

BPR28-43AD-11040

—

79

Adjust spacer

BPR28-43AD-11041

—

79

Adjust spacer

BPR28-43AD-11042

—

79

Adjust spacer

BPR28-43AD-11043

—

79

Adjust spacer

BPR28-43AD-11044

—

79

Adjust spacer

BPR28-43AD-11045

—

79

Adjust spacer

BPR28-43AD-11046

—

79

Adjust spacer

BPR28-43AD-11047

—

79

Adjust spacer

BPR28-43AD-11048

—

79

Adjust spacer

BPR28-43AD-11049

—

79

Adjust spacer

BPR28-43AD-11050

—

79

Adjust spacer

BPR28-43AD-11051

—

79

Adjust spacer

BPR28-43AD-11052

—

79

Adjust spacer

BPR28-43AD-11053

—

79

Adjust spacer

BPR28-43AD-11054

—

79

Adjust spacer

BPR28-43AD-11055

—

79

Adjust spacer

BPR28-43AD-11056

—

79

Adjust spacer

BPR28-43AD-11057

—

79

Adjust spacer

BPR28-43AD-11058

—

79

Adjust spacer

BPR28-43AD-11059

—

79

Adjust spacer

BPR28-43AD-11060

—

79

Adjust spacer

BPR28-43AD-11061

—

79

Adjust spacer

BPR28-43AD-11062

—

79

Adjust spacer

BPR28-43AD-11063

—

79

Adjust spacer

BPR28-43AD-11064

—

79

Adjust spacer

BPR28-43AD-11067

—

79

Adjust spacer

BPR28-43AD-11068

—

79

Adjust spacer

BPR28-43AD-11065

—

79

Adjust spacer

BPR28-43AD-11066

—

80

Tapered roller bearing

2402730-ZD99A

—

81

Dive pinion oil seal

2402060-ZD01K

—

82

O type sealing ring

SIMRIT55572NBR872

—

83

Flange and dust cover assy

B28-51CC-11071

—

84

Drive pinion bearing adjusting nut

HN162

—

85

Washer

Q40405

—

86

Bolt

Q2180510

—

Каталог запасных частей к технике: Golden Dragon XML6125CN-3150244. REAR AXLE ASSY
